www.ti.com
TLV320AIC34
SLAS538A–OCTOBER 2007–REVISED NOVEMBER 2007
Page 0 / Register 12:
Audio Codec Digital Filter Control Register
READ/
WRITE
R/W
RESET
VALUE
00
BIT
DESCRIPTION
D7–D6
Left-ADC High-Pass Filter Control
00: Left-ADC high-pass filter disabled
01: Left-ADC high-pass filter –3-dB frequency = 0.0045
×
ADC f
S
10: Left-ADC high-pass filter –3-dB frequency = 0.0125
×
ADC f
S
11: Left-ADC high-pass filter –3-dB frequency = 0.025
×
ADC f
S
Right-ADC High-Pass Filter Control
00: Right-ADC high-pass filter disabled
01: Right-ADC high-pass filter –3-dB frequency = 0.0045
×
ADC f
S
10: Right-ADC high-pass filter –3-dB frequency = 0.0125
×
ADC f
S
11: Right-ADC high-pass filter –3-dB frequency = 0.025
×
ADC f
S
Left-DAC Digital Effects Filter Control
0: Left-DAC digital effects filter disabled (bypassed)
1: Left-DAC digital effects filter enabled
Left-DAC De-Emphasis Filter Control
0: Left-DAC de-emphasis filter disabled (bypassed)
1: Left-DAC de-emphasis filter enabled
Right-DAC Digital Effects Filter Control
0: Right-DAC digital effects filter disabled (bypassed)
1: Right-DAC digital effects filter enabled
Right-DAC De-Emphasis Filter Control
0: Right-DAC de-emphasis filter disabled (bypassed)
1: Right-DAC de-emphasis filter enabled
D5–D4
R/W
00
D3
R/W
0
D2
R/W
0
D1
R/W
0
D0
R/W
0
Page 0 / Register 13:
Headset / Button Press Detection Register A
READ/
WRITE
R/W
RESET
VALUE
0
BIT
DESCRIPTION
D7
Headset Detection Control
0: Headset detection disabled
1: Headset detection enabled
Headset Type Detection Results
00: No headset detected
01: Headset without microphone detected
10: Ignore (reserved)
11: Headset with microphone detected
Headset Glitch Suppression Debounce Control for Jack Detection
000: Debounce = 16 ms (sampled with 2-ms clock)
001: Debounce = 32 ms (sampled with 4-ms clock)
010: Debounce = 64 ms (sampled with 8-ms clock)
011: Debounce = 128 ms (sampled with 16-ms clock)
100: Debounce = 256 ms (sampled with 32-ms clock)
101: Debounce = 512 ms (sampled with 64-ms clock)
110–111: Reserved. Do not write these sequences to these register bits.
Headset Glitch Suppression Debounce Control for Button Press
00: Debounce = 0 ms
01: Debounce = 8 ms (sampled with 1-ms clock)
10: Debounce = 16 ms (sampled with 2-ms clock)
11: Debounce = 32 ms (sampled with 4-ms clock)
D6–D5
R
00
D4–D2
R/W
000
D1–D0
R/W
00
Copyright 2007, Texas Instruments Incorporated
Submit Documentation Feedback
57
Product Folder Link(s):
TLV320AIC34
