Channel X Task File Register 0
Address Offset: 80H / C0H / 280H / 2C0H
Access Type: Read/Write
Reset Value: 0x0000_0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Starting Sector Number
Sector Count
Features (W) Error (R)
Data (byte access)
Data (word access)
Data (dword access)
This register contains some of the Channel X Task File registers and provides access to the data bus. Access to
this register is determined by the PCI bus Byte Enables at the time of the read or write operation, i.e., what is
accessed is determined by the address and by the size of the access. The register bits are defined below.
Bit [31:00]: Data (R/W). This bit field provides access to the Channel X Data. This register can be
accessed as an 8-bit, 16-bit, or 32-bit word.
Bit [31:24]: Task File Starting Sector Number (R/W). This bit field defines the Channel X Task File Starting
Sector Number register. Access to this bit field is permitted if the PCI bus Byte Enable is active for this byte
only.
Bit [23:16]: Task File Sector Count (R/W). This bit field defines the Channel X Task File Sector Count
register. Access to this bit field is permitted if the PCI bus Byte Enable is active for this byte only.
Bit [15:08]: Task File Features (W). This write-only bit field defines the Channel X Task File Features
register. Access to this bit field is permitted if the PCI bus Byte Enable is active for this byte only.
Bit [15:08]: Task File Error (R). This read-only bit field defines the Channel X Task File Error register.
Access to this bit field is permitted if the PCI bus Byte Enable is active for this byte only.
Channel X Task File Register 1
Address Offset: 84H / C4H / 284H / 2C4H
Access Type: Read/Write
Reset Value: 0x0000_0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Command + Status
Device+Head
Cylinder High
Cylinder Low
This register defines one of the Channel X Task File registers in the SiI3114. Access to these bit fields is
permitted if the PCI bus Byte Enables are active for one byte only.
The Channel 0 Device Select bit (bit 4 of the byte, bit 20 of this register) MUST be 0 for proper operation of the
Channel 0 and Channel 2 registers when accessed via Base Address 5. The Channel 1 Device Select bit (bit 4 of
the byte, bit 20 of this register) MUST be 0 for proper operation of the Channel 1 and Channel 3 registers when
accessed via Base Address 5. The Device Select bit in the Channel 2 or Channel 3 Device+Head Task File is
ignored.
The register bits are defined below.
Bit [31:24]: Task File Command (W). This write-only bit field defines the Channel X Task File Command
register.
Bit [31:24]: Task File Status (R). This read-only bit field defines the Channel X Task File Status register.
Bit [23:16]: Task File Device+Head (R/W). This bit field defines the Channel X Task File Device and Head
register.
