CHAPTER 1: OUTLINE
CHAPTER
1OUTLINE
The S1C63567 is a microcomputer which has a high-performance 4-bit CPU S1C63000 as the core
CPU, ROM (16,384 words
× 13 bits), RAM (5,120 words × 4 bits), serial interface, watchdog timer, pro-
grammable timer, time base counters (2 systems), SVD circuit, a dot-matrix LCD driver that can drive a
maximum 60 segments
× 17 commons, DTMF/DP generator and sound generator built-in. The S1C63567
features high speed operation and low current consumption in an operating voltage range (2.2 V to 5.5
V), this makes it suitable for applications working with batteries. It is also suitable for caller ID and
portable data bank systems because it has a large capacity of RAM built-in.
1.1 Features
OSC1 oscillation circuit ......................
32.768 kHz (Typ.) crystal or 60 kHz (Typ.) CR oscillation circuit (
1)
OSC3 oscillation circuit ......................
3.58 MHz (Typ.) ceramic or 1.8 MHz (Typ.) CR oscillation circuit (
1)
Instruction set .....................................
Basic instruction: 46 types (411 instructions with all)
Addressing mode: 8 types
Instruction execution time ...................
During operation at 32.768 kHz: 61 sec 122 sec 183 sec
During operation at 3.58 MHz: 0.56 sec 1.12 sec 1.68 sec
ROM capacity .....................................
Code ROM:
16,384 words
× 13 bits
Data ROM:
2,048 words
× 4 bits (= 8K bits)
RAM capacity ......................................
Data memory:
5,120 words
× 4 bits
Display memory: 1,020 bits (240 words
× 4 bits + 60 × 1 bit)
Input port .............................................
8 bits
(Pull-up resistors may be supplemented
1)
Output port ..........................................
12 bits (It is possible to switch the 8 bits to special output
2)
I/O port ................................................
16 bits (It is possible to switch the 2 bits to special output and the
4 bits to serial I/F input/output
2)
Serial interface ....................................
Built-in (8-bit clock synchronous or asynchronous system is selectable)
LCD driver ...........................................
60 segments
× 8, 16 or 17 commons (2)
Time base counter ..............................
2 systems (Clock timer, stopwatch timer)
Programmable timer ...........................
Built-in, 2 inputs
× 8 bits, with event counter function
Watchdog timer ...................................
Built-in
DTMF generator .................................
Built-in
DP generator ......................................
Built-in
Sound generator .................................
With envelope and 1-shot output functions
Supply voltage detection (SVD) circuit ...
12 values, programmable (2.20 V to 3.30 V)
(It is possible to switch 1 value to the external voltage detection
1)
External interrupt ................................
Input port interrupt:
2 systems
Internal interrupt .................................
Clock timer interrupt:
4 systems
Stopwatch timer interrupt:
2 systems
Programmable timer interrupt: 2 systems
Serial interface interrupt:
3 systems
Dialer interrupt:
1 system
Power supply voltage ..........................
2.2 V to 5.5 V
Operating temperature range .............
-20°C to 70°C
Current consumption (Typ.) ................
Low-speed operation (OSC1: crystal oscillation):
During HALT (32 kHz)
3.0 V (LCD power OFF)
1.5 A
3.0 V (LCD power ON)
4 A
During operation (32 kHz)
3.0 V (LCD power ON)
10 A
High-speed operation (OSC3: ceramic oscillation):
During operation (3.58 MHz) 3.0 V (LCD power ON)
600 A
Package ..............................................
QFP8-144pin (plastic) or chip
1: Can be selected with mask option 2: Can be selected with software
