Preliminary data sheet
1
LH7A400
Preliminary data sheet
32-Bit System-on-Chip
FEATURES
32-bit ARM9TDMI RISC Core
– 16 kB Cache: 8 kB Instruction and 8 kB Data
– MMU (Windows CE Enabled)
– Up to 250 MHz; see Table 1 for options
80 kB On-Chip Static RAM
Programmable Interrupt Controller
External Bus Interface
– Up to 125
MHz; see Table 1 for options
– Asynchronous SRAM/ROM/Flash
– Synchronous DRAM/Flash
– PCMCIA
– CompactFlash
Clock and Power Management
– 32.768 kHz and 14.7456 MHz Oscillators
– Programmable PLL
Programmable LCD Controller
– Up to 1,024 × 768 Resolution
– Supports STN, Color STN, AD-TFT, HR-TFT, TFT
– Up to 64 k-Colors and 15 Gray Shades
DMA (10 Channels)
– AC97
– MMC
– USB
USB Device Interface (USB 2.0, Full Speed)
Synchronous Serial Port (SSP)
– Motorola SPI
– Texas Instruments SSI
– National MICROWIRE
Three Programmable Timers
Three UARTs
– Classic IrDA (115 kbit/s)
Smart Card Interface (ISO7816)
Two DC-to-DC Converters
MultiMediaCard Interface
AC97 Codec Interface
Smart Battery Monitor Interface
Real Time Clock (RTC)
Up to 60 General Purpose I/Os
Watchdog Timer
JTAG Debug Interface and Boundary Scan
Operating Voltage
– 1.8 V Core
– 3.3 V Input/Output
5 V Tolerant Digital Inputs (except oscillator pins)
– Oscillator pins P15, P16, R13, and T13 are
1.8 V ± 10 %.
Operating Temperature:
40°C to +85°C
256-ball BGA or 256-ball LFBGA Package
DESCRIPTION
The LH7A400, powered by an ARM922T, is a com-
plete System-on-Chip with a high level of integration to
satisfy a wide range of requirements and expectations.
This high degree of integration lowers overall
system costs, reduces development cycle time and
accelerates product introduction.
Table 1. LH7A400 versions
PART NUMBER
CORE
CLOCK
BUS
CLOCK
LOW POWER CURRENT BY MODE (TYP.)
TEMP. RANGE
LH7A400N0F076B5
250 MHz/
245 MHz
125 MHz
Run = 250 mA; Halt = 50 mA; Standby = 129
μ
A
0°C to +70°C/
40°C to +85°C
LH7A400N0F000B3A
200 MHz/
195 MHz
100 MHz
Run = 125 mA; Halt: 25 mA; Standby = 42
μ
A
0°C to +70°C/
40°C to +85°C
0°C to +70°C/
40°C to +85°C
0°C to +70°C/
40°C to +85°C
LH7A400N0F000B5
200 MHz/
195 MHz
100 MHz
Run = 125 mA; Halt: 25 mA; Standby = 42
μ
A
LH7A400N0G000B5
200 MHz/
195 MHz
100 MHz
Run = 125 mA; Halt: 25 mA; Standby = 42
μ
A
相關PDF資料
PDF描述
LH7A404N0F000B3 32-Bit System-on-Chip
LH7A404N0F092B3 32-Bit System-on-Chip
LLNRK LLNRK/LLSRK Series POWR-PRO Class RK1
LLZ4V7 500mW Hermetically Sealed Glass Zener Voltage Regulators
LLZ43V 500mW Hermetically Sealed Glass Zener Voltage Regulators
