Table 6-2. CR000 Capture Trigger and Valid Edges of TI000 and TI010 Pins
(1) TI000 pin valid edge selected as capture trigger (CRC001 = 1, CRC000 = 1)
TI000 Pin Valid Edge
CR000 Capture Trigger
ES001
ES000
Falling edge
Rising edge
0
1
Rising edge
Falling edge
0
No capture operation
Both rising and falling edges
1
(2) TI010 pin valid edge selected as capture trigger (CRC001 = 0, CRC000 = 1)
TI010 Pin Valid Edge
CR000 Capture Trigger
ES101
ES100
Falling edge
0
Rising edge
0
1
Both rising and falling edges
1
Remarks 1. Setting ES001, ES000 = 1, 0 and ES101, ES100 = 1, 0 is prohibited.
2. ES001, ES000:
Bits 5 and 4 of prescaler mode register 00 (PRM00)
ES101, ES100:
Bits 7 and 6 of prescaler mode register 00 (PRM00)
CRC001, CRC000: Bits 1 and 0 of capture/compare control register 00 (CRC00)
Cautions 1. Set a value other than 0000H to CR000 in the mode in which clear & start occurs on a match
of TM00 and CR000.
2. If CR000 is set to 0000H in the free-running mode and in the clear mode using the valid edge
of the TI000 pin, an interrupt request (INTTM000) is generated when the value of CR000
changes from 0000H to 0001H following TM00 overflow (FFFFH). Moreover, INTTM000 is
generated after a match of TM00 and CR000 is detected, a valid edge of the TI010 pin is
detected, or the timer is cleared by a one-shot trigger.
3. When P01 is used as the valid edge input pin of TI010, it cannot be used as the timer output
(TO00). Moreover, when P01 is used as TO00, it cannot be used as the valid edge input pin
of TI010.
4. When CR000 is used as a capture register, read data is undefined if the register read time
and capture trigger input conflict (the capture data itself is the correct value).
If timer count stop and capture trigger input conflict, the captured data is undefined.
5. Do not rewrite CR000 during TM00 operation.
