SLES135E
– FEBRUARY 2005 – REVISED APRIL 2011
Table 3-90. RAM Version LSB
Subaddress
82h
Read only
7
6
5
4
3
2
1
0
RAM version LSB [7:0]
RAM version LSB [7:0]: This register identifies the LSB of the RAM code revision number.
Example:
Patch Release = v04.04.02
ROM Version = 04h
RAM Version MSB = 04h
RAM Version LSB = 02h
Table 3-91. Color PLL Speed Control
Subaddress
83h
Default
09h
7
6
5
4
3
2
1
0
Speed[3:0]
Color PLL speed control.
Table 3-92. 3DYC Luma Coring LSB
Subaddress
84h
Default
20h/20h
7
6
5
4
3
2
1
0
3DYC Luma Coring [7:0]
This register contains the lower 8 bits of the 10-bit 3DYC luma coring register. The upper 2 bits are accessed through I2C register 86h.
An inter-frame luma signal difference smaller than the programmed value is assumed to be noise, resulting in the pixel being recognized as
"no motion" hence favoring intra-frame (3D) comb filtering. The minimum value of 000h favors the 2D comb filter output, whereas the
maximum value of 3FFh favors the 3D comb filter output.
Table 3-93. 3DYC Chroma Coring LSB
Subaddress
85h
Default
20h/2Ah
7
6
5
4
3
2
1
0
3DYC Chroma Coring [7:0]
This register contains the lower 8 bits of the 10-bit 3DYC chroma coring register. The upper 2 bits are accessed through I2C register 86h.
An inter-frame chroma signal difference smaller than the programmed value is assumed to be noise, resulting in the pixel being recognized
as "no motion" hence favoring intra-frame (3D) comb filtering. The minimum value of 000h favors the 2D comb filter output whereas the
maximum value of 3FFh favors the 3D comb filter output.
Table 3-94. 3DYC Luma/Chroma Coring MSB
Subaddress
86h
Default
00h/00h
7
6
5
4
3
2
1
0
Reserved
Chroma Coring [9:8]
Luma Coring [9:8]
This register contains the upper 2 bits of the 10-bit 3DYC luma coring and 3DYC chroma coring registers. The lower 8 bits are accessed
through I2C registers 84h and 85h.
An inter-frame luma signal difference smaller than the programmed value is assumed to be noise, resulting in the pixel being recognized as
"no motion" hence favoring intra-frame (3D) comb filtering. The minimum value of 000h favors the 2D comb filter output, whereas the
maximum value of 3FFh favors the 3D comb filter output.
74
Internal Control Registers
Copyright
2005–2011, Texas Instruments Incorporated
focus.ti.com: TVP5160
