| 型號： | SAB-C163-16F25F |
| 廠商： | INFINEON TECHNOLOGIES AG |
| 元件分類： | 微控制器/微處理器 |
| 英文描述： | 16-BIT, FLASH, 25 MHz, MICROCONTROLLER, PQFP100 |
| 封裝： | METRIC, PLASTIC, TQFP-100 |
| 文件頁數： | 3/66頁 |
| 文件大?。?/td> | 669K |
| 代理商： | SAB-C163-16F25F |
第1頁第2頁當前第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁第60頁第61頁第62頁第63頁第64頁第65頁第66頁
1997 Intermediate Version
Semiconductor Group
11
1997-10-01
C163-16F
Memory Organization
The memory space of the C163-16F is configured in a Von Neumann architecture which means that
code memory, data memory, registers and I/O ports are organized within the same linear address
space which includes 16 MBytes. The entire memory space can be accessed bytewise or wordwise.
Particular portions of the on-chip memory have additionally been made directly bit addressable.
The C163-16F incorporates 128 KByte of on-chip Flash memory, organized as four 32 KByte
sectors. Each sector can be separately erased and programmed. A detailled description of the
Flash memory can be found later in this data sheet.
1 KByte of on-chip RAM is provided as a storage for user defined variables, for the system stack,
general purpose register banks and even for code. A register bank can consist of up to 16 wordwide
(R0 to R15) and/or bytewide (RL0, RH0, …, RL7, RH7) so-called General Purpose Registers
(GPRs).
1024 bytes (2 * 512 bytes) of the address space are reserved for the Special Function Register
areas (SFR space and ESFR space). SFRs are wordwide registers which are used for controlling
and monitoring functions of the different on-chip units. Unused SFR addresses are reserved for
other/future members of the C16x family.
In order to meet the needs of designs where more memory is required than is provided on chip, up
to 16 MBytes of external RAM and/or ROM can be connected to the microcontroller.
