LH75401/LH75411
System-on-Chip
6
Rev. 01
—
16 July 2007
Preliminary data sheet
NXP Semiconductors
LH75401 Numerical Pin Listing
Table 2. LH75401 Numerical Pin List
PIN
NO.
FUNCTION
AT RESET
FUNCTION
2
FUNCTION
3
FUNCTION
TYPE
OUTPUT
DRIVE
BUFFER
TYPE
BEHAVIOR DURING
RESET
NOTES
1
PA7
D15
I/O
8 mA
Bidirectional
Pull-up
1
2
PA6
D14
I/O
8 mA
Bidirectional
Pull-up
1
3
VDD
Power
None
4
PA5
D13
I/O
8 mA
Bidirectional
Pull-up
1
5
PA4
D12
I/O
8 mA
Bidirectional
Pull-up
1
6
PA3
D11
I/O
8 mA
Bidirectional
Pull-up
1
7
PA2
D10
I/O
8 mA
Bidirectional
Pull-up
1
8
VSS
Ground
None
9
PA1
D9
I/O
8 mA
Bidirectional
Pull-up
1
10
PA0
D8
I/O
8 mA
Bidirectional
Pull-up
1
11
VDDC
Power
None
12
D7
I/O
8 mA
Bidirectional
Pull-up
13
D6
I/O
8 mA
Bidirectional
Pull-up
14
VSSC
Ground
None
15
D5
I/O
8 mA
Bidirectional
Pull-up
16
D4
I/O
8 mA
Bidirectional
Pull-up
17
VDD
Power
None
18
D3
I/O
8 mA
Bidirectional
Pull-up
19
D2
I/O
8 mA
Bidirectional
Pull-up
20
D1
I/O
8 mA
Bidirectional
Pull-up
21
D0
I/O
8 mA
Bidirectional
Pull-up
22
nWE
8 mA
Output
HIGH
3
23
nOE
8 mA
Output
HIGH
3
24
PB5
nWAIT
8 mA
Bidirectional
Pull-up
1, 3
25
PB4
nBLE1
8 mA
Bidirectional
Pull-up
1, 3
26
VSS
Ground
None
27
PB3
nBLE0
8 mA
Bidirectional
Pull-up
1, 3
28
PB2
nCS3
8 mA
Bidirectional
Pull-up
1, 3
29
PB1
nCS2
8 mA
Bidirectional
Pull-up
1, 3
30
PB0
nCS1
8 mA
Bidirectional
Pull-up
1, 3
31
nCS0
8 mA
Output
Pull-up
3
32
PC7
A23
8 mA
Bidirectional
Pull-down
1
33
PC6
A22
8 mA
Bidirectional
Pull-down
1
34
VDD
Power
None
35
PC5
A21
8 mA
Bidirectional
Pull-down
1
36
PC4
A20
8 mA
Bidirectional
Pull-down
1
37
PC3
A19
8 mA
Bidirectional
Pull-down
1
38
PC2
A18
8 mA
Bidirectional
Pull-down
1
