TPS77901, TPS77918, TPS77925, TPS77930
250-mA LDO REGULATOR WITH INTEGRATED RESET IN A MSOP8 PACKAGE
SLVS283A – MARCH 2000 – REVISED MARCH 2000
2
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
description (continued)
The device is enabled when the EN pin is connected to a high-level input voltage. This LDO family also features
a sleep mode; applying a TTL low signal to EN (enable) shuts down the regulator, reducing the quiescent current
to less than 1
μ
A at T
J
= 25
°
C.
The TPS779xx features an integrated power-on reset, commonly used as a supply voltage supervisor (SVS),
or reset output voltage. The RESET output of the TPS779xx initiates a reset in DSP, microcomputer or
microprocessor systems at power-up and in the event of an undervoltage condition. An internal comparator in
the TPS779xx monitors the output voltage of the regulator to detect an undervoltage condition on the regulated
output voltage. When OUT
reaches 95% of its regulated voltage, RESET will go to a high-impedance state after
a 220 ms delay. RESET will go to low-impedance state when OUT
is pulled below 95% (i.e. over load condition)
of its regulated voltage.
AVAILABLE OPTIONS
TJ
OUTPUT
VOLTAGE
(V)
PACKAGED DEVICES
TYP
MSOP
(DGK)
3.0
TPS77930DGK
2.5
TPS77925DGK
–40
°
C to 125
°
C
1.8
TPS77918DGK
Adjustable
1.5 V to 5.5 V
TPS77901DGK
The TPS77901 is programmable using an external resistor divider (see
application information). The DGK package is available taped and
reeled. Add an R suffix to the device type (e.g., TPS77901DGKR).
OUT
SENSE
6
5
3
IN
IN
EN
GND
4
7
1
VI
0.1
μ
F
10
μ
F
+
OUT
8
VO
RESET Output
RESET
2
Figure 1. Typical Application Configuration (For Fixed Output Options)
