MFRC500_33
All information provided in this document is subject to legal disclaimers.
NXP B.V. 2010. All rights reserved.
Product data sheet
PUBLIC
Rev. 3.3 — 15 March 2010
048033
11 of 110
NXP Semiconductors
MFRC500
Highly Integrated ISO/IEC 14443 A Reader IC
9.2.1
Product information field (read only)
Table 7.
Byte
Symbol
Access
Table 8.
Byte
15
Table 9.
Definition
Byte
Value
[1]
Byte 4 contains the current version number.
9.2.2
Register initialization files (read/write)
Register initialization from address 10h to address 2Fh is performed automatically during
the initializing phase (see
Section 9.7.3 on page 25
) using the StartUp register
initialization file.
In addition, the MFRC500 registers can be initialized using values from the register
initialization file when the LoadConfig command is executed (see
Section 11.4.1 on
page 79
).
Remark:
The following points apply to initialization:
the Page register (addressed using 10h, 18h, 20h, 28h) is skipped and not initialized.
PreSetxx registers: do not change.
all reserved register bits set to logic 0: do not change.
9.2.2.1
StartUp register initialization file (read/write)
The EEPROM memory block address 1 and 2 contents are used to automatically set the
register subaddresses 10h to 2Fh during the initialization phase. The default values stored
in the EEPROM during production are shown in
Section 9.2.2.2 “Factory default StartUp
register initialization file”
.
Product information field byte allocation
15
14
13
12
CRC
Internal
R
R
11
Product Serial Number
R
10
9
8
7
6
-
R
5
4
3
2
1
0
Product Type Identification
R
Product information field byte description
Symbol
CRC
Access Value Description
R
-
the content of the product information field
is secured using a CRC byte which is
checked during start-up
three bytes for internal trimming parameters
a unique four byte serial number for the
device
14 to 12 Internal
11 to 8
R
R
-
-
Product Serial Number
7 to 5
4 to 0
reserved
Product Type
Identification
R
R
-
-
the MFRC500 is a member of a new family
of highly integrated reader ICs. Each
member of the product family has a unique
product type identification. The value of the
product type identification is shown in
Table 9
.
Product type identification definition
Product type identification bytes
0
30h
1
88h
2
F8h
3
00h
4
[1]
XXh
