WARP2 SERIES IGBT WITH
ULTRAFAST SOFT RECOVERY DIODE
IRGP50B60PDPbF
1
www.irf.com
12/1/04
Features
NPT Technology, Positive Temperature Coefficient
Lower V
CE
(SAT)
Lower Parasitic Capacitances
Minimal Tail Current
HEXFRED Ultra Fast Soft-Recovery Co-Pack Diode
Tighter Distribution of Parameters
Higher Reliability
Benefits
Parallel Operation for Higher Current Applications
Lower Conduction Losses and Switching Losses
Higher Switching Frequency up to 150kHz
E
G
n-channel
C
V
CES
= 600V
V
CE(on)
typ. = 2.00V
@ V
GE
= 15V
I
C
= 33A
Equivalent MOSFET
Parameters
R
CE(on)
typ. = 61m
I
D
(FET equivalent) = 50A
Applications
Telecom and Server SMPS
PFC and ZVS SMPS Circuits
Uninterruptable Power Supplies
Consumer Electronics Power Supplies
Lead- Free
TO-247AC
G
C
E
SMPS IGBT
Absolute Maximum Ratings
Parameter
Max.
600
75
42
150
150
50
25
100
±20
370
150
Units
V
V
CES
I
C
@ T
C
= 25°C
I
C
@ T
C
= 100°C
I
CM
I
LM
I
F
@ T
C
= 25°C
I
F
@ T
C
= 100°C
I
FRM
V
GE
P
D
@ T
C
= 25°C
P
D
@ T
C
= 100°C
T
J
T
STG
Collector-to-Emitter Voltage
Continuous Collector Current
Continuous Collector Current
Pulse Collector Current (Ref. Fig. C.T.4)
Clamped Inductive Load Current
Diode Continous Forward Current
Diode Continous Forward Current
Maximum Repetitive Forward Current
Gate-to-Emitter Voltage
Maximum Power Dissipation
Maximum Power Dissipation
Operating Junction and
Storage Temperature Range
Soldering Temperature for 10 sec.
Mounting Torque, 6-32 or M3 Screw
A
V
W
-55 to +150
°C
300 (0.063 in. (1.6mm) from case)
10 lbf·in (1.1 N·m)
Thermal Resistance
Parameter
Min.
–––
–––
–––
–––
–––
Typ.
–––
–––
0.50
–––
6.0 (0.21)
Max.
0.34
0.64
–––
40
–––
Units
°C/W
R
θ
JC
(IGBT)
R
θ
JC
(Diode)
R
θ
CS
R
θ
JA
Thermal Resistance Junction-to-Case-(each IGBT)
Thermal Resistance Junction-to-Case-(each Diode)
Thermal Resistance, Case-to-Sink (flat, greased surface)
Thermal Resistance, Junction-to-Ambient (typical socket mount)
Weight
g (oz)
