DAC1627D1G25
All information provided in this document is subject to legal disclaimers.
NXP B.V. 2011. All rights reserved.
Objective data sheet
Rev. 1 — 29 April 2011
42 of 69
NXP Semiconductors
DAC1627D1G25
Dual 16-bit DAC: up to 1.25 Gsps; x2, x4 and x8 interpolating
Table 28.
Default values are shown highlighted.
Bit
Symbol
7 to 0
FREQ_NCO[15:8]
Register FREQNCO_B1 (address 05h)
Access
R/W
Value
Description
NCO frequency
intermediate 8 bits for the NCO frequency setting
-
Table 29.
Default values are shown highlighted.
Bit
Symbol
7 to 0
FREQ_NCO[23:16]
Register FREQNCO_B2 (address 06h)
Access
R/W
Value
Description
NCO frequency
intermediate 8 bits for the NCO frequency setting
-
Table 30.
Default values are shown highlighted.
Bit
Symbol
7 to 0
FREQ_NCO[31:24]
Register FREQNCO_B3 (address 07h)
Access
R/W
Value
Description
NCO frequency
intermediate 8 bits for the NCO frequency setting
-
Table 31.
Default values are shown highlighted.
Bit
Symbol
7 to 0
FREQ_NCO[39:32]
Register FREQNCO_B4 (address 08h)
Access
R/W
Value
Description
NCO frequency (MSB)
most significant 8 bits for the NCO frequency setting
-
Table 32.
Default values are shown highlighted.
Bit
Symbol
7 to 0
PHASE_COR[7:0]]
Register PH_CORR_CTL0 (address 09h)
Access
R/W
Value
Description
DAC output phase correction factor (LSB)
least significant 8 bits for the DAC output phase
correction factor
-
Table 33.
Default values are shown highlighted.
Bit
Symbol
7
PH_COR_ENA
Register PH_CORR_CTL1 (address 0Ah)
Access
R/W
Value
Description
DAC output phase correction control
DAC output phase correction disabled
DAC output phase correction enabled
DAC output phase correction factor MSB
most significant 5 bits for the DAC output phase
correction factor
0
1
4 to 0
PHASE_COR[12:8]
R/W
00000
Table 34.
Default values are shown highlighted.
Bit
Symbol
7 to 0
DAC_A_DGAIN[7:0]
Register DAC_A_DGAIN_LSB (address 0Bh)
Access
R/W
Value
Description
DAC A digital gain control
least significant 8 bits for the DAC A digital gain
-
