TFP6422, TFP6424
PanelBus
DIGITAL TRANSMITTER/VIDEO ENCODER COMBO
SLDS118 – MARCH 2000
58
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
FUS_TST0–3
Subaddress = B4–B7
7
6
5
4
3
2
1
0
FUSEA[7:0]
7
6
5
4
3
2
1
0
FUSEA[15:8]
7
6
5
4
3
2
1
0
FUSEB[7:0]
7
6
5
4
3
2
1
0
FUSEB[15:8]
TMDS_TST0
Subaddress = C0
TMDS_TST1
Subaddress = C1
TMDS_TST2
Subaddress = C2
TMDS_TST3
Subaddress = C3
TMDS_TST4
Subaddress = C4
TMDS_TST5
Subaddress = C5
TMDS_TST6
Subaddress = C6
TMDS_TST7
Subaddress = C7
TMDS_TST8
Subaddress = C8
TMDS_TST9
Subaddress = C9
TMDS_TST10
Subaddress = CA
TMDS_TST11
Subaddress = CB
TMDS_TST12
Subaddress = CC
TMDS_TST13
Subaddress = CD
TMDS_TST14
Subaddress = CE
TMDS_TST15
Subaddress = CF
DAC_TST
Subaddress = D0
Default = 0x00
7
6
5
4
3
2
1
0
DAC_DX
DACX3
DACX2
DACX1
DACX0
DAC_DX
Direct DAC output
0*
DACs are in normal operation
1
Video port DATA[9:0] is directly connected to DACs for testing output. DACX[3:0] will select
which DACs to output.
DACX3
0
DAC3 at pin 40 is shut down
1
DAC3 outputs DATA [9:0]
DACX2
0
DAC2 at pin 41 is shut down
1
DAC2 outputs DATA [9:0]
DACX1
0
DAC1 at pin 43 is shut down
1
DAC1 outputs DATA [9:0]
DACX0
0
DAC0 at pin 44 is shut down
1
DAC0 outputs DATA [9:0]
