TFP6422, TFP6424
PanelBus
DIGITAL TRANSMITTER/VIDEO ENCODER COMBO
SLDS118 – MARCH 2000
55
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
BAVID
Subaddress = 77
Default = 0x00
7
6
5
4
3
2
1
0
BAVID[7:0]
Beginning of active video.
BAVID[7:0]
EAVID
Subaddress = 78
Default = 0x00
7
6
5
4
3
2
1
0
EAVID[7:0]
End of active video.
EAVID[7:0]
BEAVID
Subaddress = 79
Default = 0x00
7
6
5
4
3
2
1
0
EAVID[10:8]
BAVID[10:8]
Overflow register for BAVID and EAVID fields.
FLEN
Subaddress = 7A
Default = 0x0C
7
6
5
4
3
2
1
0
FLEN[7:0]
Field Length
FLEN[7:0]
These bits define the number of half_lines in each field. The upper 2 bits of this register are located in
FLAL register.
Length of field = (FLEN + 1) half_lines
FAL
Subaddress = 7B
Default = 0x12
7
6
5
4
3
2
1
0
FAL[7:0]
First Active Line of Field
FAL[7:0]
These bits define the first active line of a field. The MSB is located in register FLAL.
LAL
Subaddress = 7C
Default = 0x03
7
6
5
4
3
2
1
0
LAL[7:0]
Last Active Line of Field
LAL[7:0]
These bits define the last active line of a field. The MSB is located in register FLAL.
PRODUCT
PREVIEW
