SiI3114 PCI to Serial ATA Controller
Data Sheet
Silicon Image, Inc.
2007 Silicon Image, Inc.
31
SiI-DS-0103-D
Subsystem ID – Subsystem Vendor ID
Address Offset: 2CH
Access Type: Read/Write
Reset Value: 0x3114_1095
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Subsystem ID
Subsystem Vendor ID
This register defines the Subsystem ID fields associated with the PCI bus. The register bits are defined below.
Bit [31:16]: Subsystem ID (R) – Subsystem ID. The value in this bit field is determined by any one of three
options:
1) The default value of 0x3114
2) Loaded from an external memory device: If an external memory device — flash or EEPROM — is
present with the correct signature, the Subsystem ID is loaded from that device after reset. See “Auto-
Initialization” section on page 22 for more information.
3) System programmable: If Bit 0 of the Configuration register (40H) is set the two bytes are system
programmable.
Bit [15:00]: Subsystem Vendor ID (R) – Subsystem Vendor ID. The value in this bit field is determined by
any one of three options:
1) The default value of 0x1095
2) Loaded from an external memory device : If an external memory device – Flash or EEPROM – is
present with the correct signature, the Subsystem Vendor ID is loaded from that device after reset. See
“Auto-Initialization” section on page 22 for more information.
3) System programmable: If Bit 0 of the Configuration register (40H) is set the two bytes are system
programmable.
Expansion ROM Base Address
Address Offset: 30H
Access Type: Read/Write
Reset Value: 0x0000_0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Expansion ROM Base Address
000_0000_0000_0000_000
Exp
R
O
M
Enable
This register defines the Expansion ROM base address associated with the PCI bus. The register bits are defined
below.
Bit [31:19]: Expansion ROM Base Address (R/W) – Expansion ROM Base Address. This bit field defines
the upper bits of the Expansion ROM base address.
Bit [18:01]: Not Used (R). This bit field is hardwired to 00000
H. The minimum Expansion ROM address
range is 512K bytes.
Bit [00]: Exp ROM Enable (R/W) – Expansion ROM Enable. This bit is set to enable the Expansion ROM
access.
