參數資料
| 型號： | SI5350C-AXXXXX-GU |
| 廠商： | SILICON LABORATORIES |
| 元件分類： | 時鐘產生/分配 |
| 英文描述： | 133 MHz, PROC SPECIFIC CLOCK GENERATOR, PDSO24 |
| 封裝： | MO-137C, QSOP-24 |
| 文件頁數： | 17/22頁 |
| 文件大小： | 244K |
| 代理商： | SI5350C-AXXXXX-GU |
Si5350C
4
Rev. 0.2
1. Electrical Specifications
Table 1. Recommended Operating Conditions
(VDD = 2.5 V ±10%, or 3.3 V ±10%, TA = –40 to 85°C)
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Ambient Temperature
TA
–40
25
85
°C
Core Supply Voltage
VDD
2.97
3.3
3.63
V
2.25
2.5
2.75
V
Output Buffer Voltage
VDDOx
2.97
3.3
3.63
V
2.25
2.5
2.75
V
Note: All minimum and maximum specifications are guaranteed and apply across the recommended operating conditions.
Typical values apply at nominal supply voltages and an operating temperature of 25 °C unless otherwise noted.
Table 2. Absolute Maximum Ratings
Parameter
Symbol
Test Condition
Value
Unit
DC Supply Voltage
VDD_max
–0.5 to 3.8
V
Input Voltage
VIN_P1-3
Pins P1, P2, P3
–0.5 to 3.8
V
VIN_P0
P0
–0.5 to (VDD+0.3)
V
VIN_XA/B
Pins XA, XB
–0.5 to 1.3 V
V
Storage Temperature Range
TSTG
–55 to 150
°C
Operating Junction Temperature
TJCT
–55 to 150
°C
Note: Permanent device damage may occur if the absolute maximum ratings are exceeded. Functional operation should be
restricted to the conditions specified in the operational sections of this data sheet. Exposure to absolute maximum
rating conditions for extended periods may affect device reliability.
Table 3. DC Characteristics
(VDD = 2.5 V ±10%, or 3.3 V ±10%, TA = –40 to 85 °C)
Parameter
Symbol
Test Condition
Min
Typ
Max
Unit
Core Supply Current
IDD
Enabled 3 outputs
—
20
26
mA
Enabled 8 outputs
—
25
38
mA
Power Down (PDN = VDD)—
50
—
A
Output Buffer Supply Current
IDDOx
CL =5pF
—
2.5
4
mA
Input Current
IP1-P3
Pins P1, P2, P3
Vin<3.6V
——
10
A
IP0
Pin P0
—
30
A
