Analog Integrated Circuit Device Data
46
Freescale Semiconductor
908E621
FUNCTIONAL DEVICE OPERATION
OPERATIONAL MODES
If the watchdog is enabled, it will generate a system reset,
if the timer has reached its end value, or if a watchdog reset
(WDRST) has occurred in the closed window.
The watchdog period can be selected with 2 bits in the
WDCTL, in order to get 10ms, 20ms, 40ms and 80ms period.
Figure 28. Window Watchdog Period
Stop mode
Operations of the watchdog function is halted in stop mode
(counter/oscillator stopped). After wake-up, the watchdog
timer is automatically cleared, in order to give the MCU the
full time to reset the watchdog.
Sleep mode
Operations of the watchdog function is halted in sleep
mode. Because the main voltage regulator asserts an LVR
reset, the Watchdog functionality is disabled, and the WDRE
bit is cleared as soon as sleep mode is entered. To re-enable
this function bit WDRE has to be set after wake-up.
Watchdog Control Register (WDCTL)
WDRE - Watchdog Reset Enable Bit
This read/write (write once) bit activates the watchdog.
The WDRE can only be set and can not be cleared by
software. Reset clears the WDRE bit.
1 = Watchdog enabled
0 = Watchdog disabled
WDP1:0 - Watchdog Period Select Bits
This read/write bit select the clock rate of the Watchdog.
Reset clears the WDP1:0 bits.
Table 11. Watchdog Period Selection Bits
WDRST - Watchdog Reset Bit
This write only bit resets the Watchdog. Write a logic [1] to
reset the watchdog timer.
1 = Reset WD and restart timer
0 = no effect
Voltage Regulator
The 908E621 contains a low power, low drop voltage
regulator, to provide internal power and external power for
the MCU. The on-chip regulator consist of two elements, the
main regulator and the low voltage reset circuit.
The VDD regulator accepts an unregulated input supply
and provides a regulated VDD supply to all digital sections of
the device. The output of the regulator is also connected to
the VDD pin to provide the 5.0V to the microcontroller.
Run mode
During RUN mode the main voltage regulator is on. It will
provide a regulated supply to all digital sections.
STOP mode
During STOP mode, the Stop mode regulator will take care
of suppling a regulated output voltage. The Stop mode
regulator has a limited output current capability.
SLEEP mode
In Sleep mode, the main voltage regulator external, VDD,
is turned off and the LVR circuitry will force the RST_A pin
low.
Register Name and Address: WDCTL - $0B
Bit7
6
5
4
3
2
1
Bit0
Read
WDRE
WDP1
WDP0
0
000
0
Write
WDRST
Reset
0
Window closed
no watch dog clear allowed
Window open
for watch dog clear
WD timing x 50%
WD period ( timing selected by Bits WDP1:0)
WDP1
WDP0
Mode
0
80ms window watchdog period
0
1
40ms window watchdog period
1
0
20ms window watchdog period
1
10ms window watchdog period
