153
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER with CLOSED CAPTION DECODER
and ON-SCREEN DISPLAY CONTROLLER
M37280MFH–XXXSP, M37280MKH–XXXSP
M37280EKSP
MITSUBISHI MICROCOMPUTERS
Rev. 1.0
Address 00FE16
Address 00FF16
b7 b6 b5 b4 b3 b2 b1 b0
Interrupt control register 1 (ICON1) [Address 00FE16]
B
Name
Functions
RW
Interrupt Control Register 1
0
Timer 1 interrupt
enable bit (TM1E)
0 : Interrupt disabled
1 : Interrupt enabled
1
Timer 2 interrupt
enable bit (TM2E)
2
Timer 3 interrupt
enable bit (TM3E)
3
4
OSD interrupt enable bit
(OSDE)
0 : Interrupt disabled
1 : Interrupt enabled
0 : Interrupt disabled
1 : Interrupt enabled
0 : Interrupt disabled
1 : Interrupt enabled
0
RW
R —
7
Nothing is assigned. This bit is a write disable
bit. When this bit is read out, the value is “0.”
Timer 4 interrupt
enable bit (TM4E)
0 : Interrupt disabled
1 : Interrupt enabled
5
VSYNC interrupt enable
bit (VSCE)
0 : Interrupt disabled
1 : Interrupt enabled
0R W
6
A-D conversion INT3
interrupt enable bit (ADE)
0 : Interrupt disabled
1 : Interrupt enabled
0R W
After reset
b7 b6 b5 b4 b3 b2 b1 b0
Interrupt control register 2 (ICON2) [Address 00FF16]
B
Name
Functions
R W
Interrupt Control Register 2
0
INT1 interrupt
enable bit (IN1E)
1
Data slicer interrupt
enable bit (DSE)
2
Serial I/O interrupt
enable bit (SIOE)
3
4
INT2 interrupt enable
bit (IN2E)
0
RW
f(XIN/4096 SPRITE OSD
interrupt enable bit (CKE)
5
Multi-master I2C-BUS interface
interrupt enable bit (IICE)
0R W
6
Timer 5 6 interrupt
enable bit (TM56E)
0R W
7
Timer 5 6 interrupt
switch bit (TM56S)
0R W
After reset
0: Timer 5
1: Timer 6
0: Interrupt disabled
1: Interrupt enabled
0: Interrupt disabled
1: Interrupt enabled
0: Interrupt disabled
1: Interrupt enabled
0: Interrupt disabled
1: Interrupt enabled
0: Interrupt disabled
1: Interrupt enabled
0: Interrupt disabled
1: Interrupt enabled
0: Interrupt disabled
1: Interrupt enabled
