LV23401V
No.A1746-16/24
Register 11h – IF_SEL – IF frequency selection (Read/Write)
7
6
5
4
3
2
1
0
FLL_MOD
AMIF[2:0]
FMIF[3:0]
Bit 7 :
FLL_MOD : FLL operation mode
0 : Smoothing filter = OFF
1 : Smoothing filter = ON
Bit 6 -4 :
AMIF[2:0] : IF frequency setting when AM mode is selected
AMIF[2:0]
0
1
2
3
4
5
6
7
20kHz
31kHz
42kHz
53kHz
64kHz
75kHz
86kHz
97kHz
Bit 3 – 0 :
FMIF[3:0] : IF frequency setting when FM mode is selected (kHz)
FMIF[3:0]
SE_
AM
RF_
SEL
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
112.5
125
137.5
150
162.5
175
187.5
212.5
225
237.5
250
262.5
275
287.5
312.5
325
0
1
112.5
127.5
142.5
157.5
172.5
187.5
202.5
217.5
232.5
247.5
262.5
277.5
292.5
307.5
322.5
Register 12h – REF_CLK_MOD – Slope correction (Read/Write)
7
6
5
4
3
2
1
0
REFMOD[7:0]
Bit 7 – 0 :
REFMOD[7:0] : Reference clock correction
Note : As for this register, a set value is different according to the crystal connected with 16pin and the input clock. Inform of a set value of this register
when you adopt the applications other than an example of applied circuit and recommended parts of this specifications.
