35
6:4
De-multiplex control. These control bits are provided to select a channel from a group of multiplexed channels. Up to eight
multiplexed data streams can be demultiplexed. These control bits select how many clocks after the ENIx signal to wait before taking
the input sample. ENIx should be asserted for one clock period and aligned with the first channel of the multiplexed data set. For
example, if four streams are multiplexed at half the clock rate, ENIx would align with the first clock period of the first stream, the
second would start two clocks later, the next four clocks after ENIx, etc. The samples are aligned with ENIx (zero delay) at the input
of the NCO/Mixer/CIC stage at the next ENIx.
000
Zero delay
111
All values from 0 through 7 are valid.
Seven clock periods of delay.
3
Interpolated/Gated Mode Select:
0
Gated. The carrier NCO and CIC are updated once per clock when ENIx is asserted.
1
Interpolated. The CIC is updated every clock. The carrier NCO is updated once per clock when ENIx is asserted. The
input is zeroed when ENIx is high.
2
Enable COF/COFSYNC inputs. When set, this bit enables two bits from the D(15:0) input data bus to be used as a carrier offset
frequency input.
1
Enable SOF/SOFSYNC inputs. When set, this bit enables two bits from the D(15:0) input data bus to be used as a resampler offset
frequency input.
0
Enable PN. When set, A PN code, weighted by the gain in location *001, is added to the input samples at the output of the mixer.
TABLE 4. CHANNEL INPUT SELECT/FORMAT REGISTER (IWA = *000h) (Continued)
P(31:0)
FUNCTION
TABLE 5. FLOATING POINT MODE DETAILS (IWA = *000h, BITS 17, 16, 8 and 7)
BIT 17
BIT 16
BIT 8
BIT 7
MANTISSA / EXP
EXPONENT RANGE (dB)
PIN ASSIGNMENTS:
MANTISSA BITS / EXPONENT BITS
0
X
0
0
11 to 13 / 3
30
15:5 (4 or 3) (Note 19) / 2:0
0
X
0
1
12 to 13 / 3
24
15:4 (3) / 2:0
0
X
1
0
13 / 3
18
15:3 / 2:0
0
X
1
1
14 / 2
18 maximum (Note 20)
15:2 / 1:0
1
0
0
0
11 / 3
42 maximum
15:5 / (2 logical-OR m1), 1, 0
1
0
0
1
12 / 3
42 maximum
15:4 / (2 logical-OR m1), 1, 0
1
0
1
0
13 / 3
42 maximum
15:3 / (2 logical-OR m1), 1, 0
1
0
1
1
14 / 3
42 maximum
15:2 / m1, 1, 0
1
1
0
0
15 / 2
18 maximum
15:1 / m1, 0
1
1
0
1
16 / 1
6 maximum
15:0 / m1
1
1
1
X
INVALID
INVALID
INVALID
NOTES:
19. Bits in parentheses are used as the shift gain allows.
20. Modes with “maximum” listed in exponent range use the CIC’s barrel shifter for gain, decreasing allowable CIC decimation. Maximum exponent
range may be limited, if desired, to allow for larger CIC decimation.
TABLE 6. PN GAIN REGISTER (IWA = *001h)
P(31:0)
FUNCTION
31:16
Reserved, set to all 0’s.
15:0
PN generator gain register. This input is provided to reduce the sensitivity of the receiver. A PN code, weighted by the value in this
location, is added to the data at the output of the mixer. Adding noise has the effect of increasing the receiver noise figure. One
reason to do this would be to decrease the basestation cell size in small steps. This method is very accurate and repeatable and can
be done on a FDM channel by channel basis. It does, however, reduce the overall dynamic range. An alternate way is to add
attenuation at the RF and adjust the whole range upward. This does not reduce the overall range but only shift it, with the shift being
done on all channels simultaneously.
