Data Sheet - Rev 2.1
12/2007
AWL9925 Die
3
ELECTRICAL CHARACTERISTICS
Table 2: Absolute Minimum and Maximum Ratings
Stresses in excess of the absolute ratings may cause permanent damage. Functional operation is not implied under
these conditions. Exposure to absolute ratings for extended periods of time may adversely affect reliability.
Table 3: Operating Ranges
The device may be operated safely over these conditions; however, parametric performance is guaranteed only
over the conditions defined in the electrical specifications.
Table 1: Bond Pad Description (Continued)
Bond
Pad
NAME
DESCRIPTION
17
VCC3 2G
2 GHz supply voltage. Bias for 3rd stage power transistors of the 2GHz PA.
18
VCC2 2G
2 GHz supply voltage. Bias for 1st and 2nd stage power transistors of the 2GHz PA.
19
VCC1 2G
2 GHz supply voltage. Bias for 2 GHz On/Off control circuit.
PARAMETER
MIN
MAX
UNIT
COMMENTS
DC Power Supply Voltage (VCC 2G,
VCC 5G)
-
+4.5
V
DC Power Control Voltage (PAON 2G,
PAON 5G)
-
+4.5
V
No RF signal applied.
DC Current Consumption
-
700
mA
Either PA powered separately
RF Input Level (RFIN 2G, RFIN 5G)
-
-5
dBm
Operating Case Temperature
-40
+85
°C
When mounted in reference
platform
Storage Temperature
+15
+30
°C
Extended Storage
Storage Relative Humidity
-
60
%
Shipping Temperature
-55
+150
°C
Shipping Relative Humidity
-
60
%
ESD Tolerance
1000
-
V
All pins, forward and reverse
voltage. Human body model.
PARAMETER
MIN
TYP
MAX
UNIT
COMMENTS
Operating Frequency (f)
2400
4900
-
2500
5900
MHz 802.11b/g
802.11a
DC Power Supply Voltage (VCC 2G,
VCC 5G)
+3.0
+3.3
+3.6
V
With RF Applied
On/Off Power Control Voltage (PAON 2G,
PAON 5G)
+2.0
0
+3.3
-
+3.6
+0.8
V
PA "ON"
PA "SHUTDOWN"
Operating Case Temperature (TC)
-40
-
+85
°C
When mounted in
reference platform
