41
4 Example Register Settings
The following example register settings are provided only as a reference. These settings, given the assumed input
connector, video format, and output format, set up the TVP5150A decoder and provide video output. Example register
settings for other features and the VBI data processor are not provided here.
4.1
Example 1
4.1.1
Assumptions
Device:
TVP5150AM1
Input connector:
Composite (AIP1A)
Video format:
NTSC-M, PAL (B, G, H, I), or SECAM
NOTE: NTSC-443, PAL-N, and PAL-M are masked from the autoswitch process by default.
See the autoswitch mask register at address 04h.
Output format:
8-bit ITU-R BT.656 with embedded syncs
4.1.2
Recommended Settings
Recommended I2C writes: For this setup, only one write is required. All other registers are set up by default.
I2C register address 03h = Miscellaneous controls register address
I2C data 09h = Enables YCbCr output and the clock output
NOTE: HSYNC, VSYNC/PALI, AVID, and FID/GLCO are high impedance by default. See the
miscellaneous control register at address 03h.
4.2
Example 2
4.2.1
Assumptions
Device:
TVP5150AM1
Input connector:
S-video (AIP1A (luma), AIP1B (chroma))
Video format:
NTSC-M, 443, PAL (B, G, H, I, M, N) or SECAM (B, D,G, K, KI, L)
Output format:
8-bit 4:2:2 YCbCr with discrete sync outputs
4.2.2
Recommended Settings
Recommended I2C writes: This setup requires additional writes to output the discrete sync 4:2:2 data outputs, the
HSYNC, and the VSYNC, and to autoswitch between all video formats mentioned above.
I2C register address 00h = Video input source selection #1 register
I2C data 01h = Selects the S-Video input, AIP1A (luma), and AIP1B (chroma)
I2C register address 03h = Miscellaneous controls register address
I2C data 0Dh = Enables the YCbCr output data, HSYNC, VSYNC/PALI, AVID, and FID/GLCO
I2C register address 04h = Autoswitch mask register
I2C data C0h = Unmask NTSC-443, PAL-N, and PAL-M from the autoswitch process
I2C register address 0Dh = Outputs and data rates select register
I2C data 40h = Enables 8-bit 4:2:2 YCbCr with discrete sync output
