2.20.2 Analog Channel Controls Register
Address
01h
Default
15h
7
6
5
4
3
2
1
0
Reserved
1
Automatic offset control
Automatic gain control
Automatic offset control:
00 = Disabled
01 = Automatic offset enabled (default)
10 = Reserved
11 = Offset level frozen to the previously set value
Automatic gain control (AGC):
00 = Disabled (fixed gain value)
01 = AGC enabled (default)
10 = Reserved
11 = AGC frozen to the previously set value
2.20.3 Operation Mode Controls Register
Address
02h
Default
00h
7
6
5
4
3
2
1
0
Reserved
Color burst
reference enable
TV/VCR mode
White peak
disable
Color subcarrier
PLL frozen
Luma peak
disable
Power down mode
Color burst reference enable
0 = Color burst reference for AGC disabled (default)
1 = Color burst reference for AGC enabled
TV/VCR mode
00 = Automatic mode determined by the internal detection circuit. (default)
01 = Reserved
10 = VCR (nonstandard video) mode
11 = TV (standard video) mode
With automatic detection enabled, unstable or nonstandard syncs on the input video forces the detector into the VCR
mode. This turns off the comb filters and turns on the chroma trap filter.
White peak disable
0 = White peak protection enabled (default)
1 = White peak protection disabled
Color subcarrier PLL frozen:
0 = Color subcarrier PLL increments by the internally generated phase increment. (default)
GLCO pin outputs the frequency increment.
1 = Color subcarrier PLL stops operating.
GLCO pin outputs the frozen frequency increment.
Luma peak disable
0 = Luma peak processing enabled (default)
1 = Luma peak processing disabled
Power down mode:
0 = Normal operation (default)
1 = Power down mode. A/Ds are turned off and internal clocks are reduced to minimum.
