TFP513
TI PanelBus DIGITAL TRANSMITTER
SLLS611 AUGUST 2004
6
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
absolute maximum ratings over operating free-air temperature (unless otherwise noted)
Supply voltage range, DVDD, PVDD, TVDD
0.5 V to 4 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage, logic/analog signals
0.5 V to 4 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External DVI single-ended termination resistance, R(T)
0
to open circuit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External TFADJ resistance, R(TFADJ)
300
to open circuit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range, Tstg
–65
°C to 150°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Case temperature for 10 seconds
260
°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds
260
°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ESD protection, DVI pins
4-kV Human body model
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ESD protection, all other pins
2-kV Human body model
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JEDEC latchup (EIA/JESD78)
100 mA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
recommended operating conditions
MIN
NOM
MAX
UNIT
Supply voltage, VDD (DVDD, PVDD, TVDD)
3
3.3
3.6
V
Input reference voltage, VREF
Low-swing mode
0.55
VDDQ/2
0.9
V
Input reference voltage, VREF
High-swing mode
DVDD
V
DVI termination supply voltage, AVDD (see Note 1)
At DVI receiver
3.14
3.3
3.46
V
DVI Single-ended termination resistance, R(T) (see Note 2)
At DVI receiver
45
50
55
TFADJ resistor for DVI-compliant V(SWING) range, R(TFADJ)
400 mV = V(SWING) = 600 mV
505
510
515
Operating free-air temperature range, TA
0
25
70
_C
VDDQ defines the maximum low-level input voltage, it is not an actual input voltage.
NOTES:
1. AVDD is the termination supply voltage of the DVI link.
2. R(T) is the single-ended termination resistance at the receiver end of the DVI link.
