TDA8295_C2_2
NXP B.V. 2009. All rights reserved.
Product data sheet
Rev. 02 — 27 November 2009
57 of 83
NXP Semiconductors
TDA8295
Digital global standard low IF demodulator for analog TV and FM radio
10. Limiting values
[1]
Stresses above the absolute maximum ratings may cause permanent damage to the device. Exposure to absolute maximum ratings
conditions for extended periods may affect device reliability.
[2]
The maximum allowed ambient temperature Tamb depends on the assembly condition of the package and especially on the design of
the PCB. The application mounting must be done in such a way that the maximum junction temperature Tj(max) is never exceeded.
[3]
Class A according to EIA/JESD22-A115.
[4]
Class B according to EIA/JESD22-A115.
11. Thermal characteristics
The thermal resistance depends strongly on the nature of the PCB used in the application
and on its design. The thermal resistance given in Table 71 corresponds to the value that
can be measured on a multilayer PCB (4 layers) as defined by EIA/JESD51-2. This value
is given for information only.
The junction temperature influences strongly the reliability of an IC. The PCB used in the
application contributes on a large part to the overall thermal characteristic. It must
therefore be designed to insure that the junction temperature of the IC never exceeds
Tj(max) = 125 °C at the maximum ambient temperature.
The IC has to be soldered to ground with its die-attached paddle. Plenty of vias are
recommended to remove the heat.
Table 70.
Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).[1][2]
Symbol
Parameter
Conditions
Min
Max
Unit
VDDDC(1V2)
core digital supply voltage (1.2 V)
0.5
+1.7
V
VDDA(ADC)(3V3)
ADC analog supply voltage (3.3 V)
0.5
+4.6
V
VDDA(PLL)(1V2)
PLL analog supply voltage (1.2 V)
0.5
+1.7
V
VDDA(OSC)(1V2) oscillator analog supply voltage (1.2 V)
0.5
+1.7
V
Vi
input voltage
pins IF_POS and IF_NEG
0.5
+1.7
V
digital input pins (5 V tolerant)
0.5
+5.1
V
pin XIN
0.5
+1.7
V
Tlead
lead temperature
-
300
°C
Ptot
total power dissipation
Tamb = 70 °C
-
0.5
W
Tstg
storage temperature
40
+125
°C
Tj
junction temperature
-
125
°C
Tamb
ambient temperature
20
+85
°C
Vesd
electrostatic discharge voltage
pins SDA, SCL, SADDR0 and
SADDR1; machine model
±150
V
all other pins; machine model
±200
V
Table 71.
Thermal characteristics
Symbol
Parameter
Conditions
Typ
Unit
Rth(j-a)
thermal resistance from junction to
ambient
in still air
33
K/W
