參數資料
型號： MAX6876ETX+
廠商： MAXIM INTEGRATED PRODUCTS INC
元件分類： 電源管理
英文描述： EEPROM-Programmable, Quad, Power-Supply Tracker/Sequencer Circuit
中文描述： 1-CHANNEL POWER SUPPLY SUPPORT CKT, QCC36
封裝： 6 X 6 MM, 0.80 MM HEIGHT, MO-220WJJD-1, TQFN-36
文件頁數： 35/39頁
文件大小： 425K
代理商： MAX6876ETX+
MAX6876
EEPROM-Programmable, Quad,
Power-Supply Tracker/Sequencer Circuit
_______________________________________________________________________________________
5
ELECTRICAL CHARACTERISTICS (continued)
(VCC, IN1–IN4 = +2.7V to +5.5V; ENABLE = MARGIN = MR = ABP = TRKEN; TA = -40°C to +85°C, unless otherwise specified.
Typical values are at TA = +25°C.) (Note 1)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
TRKEN Input Delay
tEN
TRKEN falling, 100mV overdrive
2
s
Input rising
1.245
1.285
1.320
TRKEN Reference Voltage Range
VTRKEN
Input falling
1.225
1.25
1.275
V
TRKEN Input Current
ITRKEN
VTRKEN = 1.25V
-100
+100
nA
Reference Input Voltage Range
VREFIN
1.225
1.25
1.275
V
Reference Input Resistance
RREFIN
VREFIN = 1.25V
500
k
SERIAL INTERFACE LOGIC (SDA, SCL, A0, A1)
Logic-Input Low Voltage
VIL
0.3 x
ABP
V
Logic-Input High Voltage
VIH
0.6 x
ABP
V
Input Leakage Current
IILKG
1A
Output-Voltage Low
VOL
ISINK = 3mA
0.4
V
Output Leakage Current
IOLKG
1A
Input/Output Capacitance
CI/O
10
pF
SERIAL INTERFACE TIMING (SDA, SCL)
Serial Clock Frequency
fSCL
400
kHz
Clock Low Period
tLOW
1.3
s
Clock High Period
tHIGH
0.6
s
Bus Free Time
tBUF
1.3
s
START Setup Time
tSU:STA
0.6
s
START Hold Time
tHD:STA
0.6
s
STOP Setup Time
tSU:STO
0.6
s
Clock Low to Valid Output
tAA
0.1
0.9
s
Data Out Hold Time
tDH
50
ns
Data In Setup Time
tSU:DAT
100
ns
Data In Hold Time
tHD:DAT
0ns
SCL/SDA Rise Time
tR
300
ns
SCL/SDA Fall Time
tF
300
ns
Transmit SDA Fall Time
tF
CBUS = 400pF
20 +
0.1 x
CBUS
300
ns
SCL/SDA Noise Suppression Time
tI
50
ns
Byte Write Cycle Time
tWR
11
ms
Note 1: Specifications guaranteed for the stated global conditions. 100% production tested at TA = +25°C and TA = +85°C.
Specifications at TA = -40°C are guaranteed by design.
Note 2: The internal supply voltage, measurable on ABP, is equal to the maximum of IN1–IN4 and VCC supplies.
Note 3: Differential between each of the OUT_ and the SYNCH ramp voltage during power-up/down measured as VOUT_ - 2 x
VSYNCH.
Note 4: FAULT timeout starts to count at the beginning of each sequence of power-up/down and clears when the programmed
OUT_ voltages track successfully.
相關PDF資料
PDF描述
MAX6876ETX+T EEPROM-Programmable, Quad, Power-Supply Tracker/Sequencer Circuit
MAX687CSA+T High-Accuracy, Low-Dropout Linear Regulators
MAX6880ETG+T Dual-/Triple-Voltage, Power-Supply Sequencers/Supervisors
MAX6881ETE+T Dual-/Triple-Voltage, Power-Supply Sequencers/Supervisors
MAX6882ETE+T Dual-/Triple-Voltage, Power-Supply Sequencers/Supervisors
相關代理商/技術參數
參數描述
MAX6876ETX+ 功能描述:監控電路 EEPROM-Prog Quad Power-Sup Sequencer RoHS:否 制造商:STMicroelectronics 監測電壓數: 監測電壓: 欠電壓閾值: 過電壓閾值: 輸出類型:Active Low, Open Drain 人工復位:Resettable 監視器:No Watchdog 電池備用開關:No Backup 上電復位延遲（典型值）:10 s 電源電壓-最大:5.5 V 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:UDFN-6 封裝:Reel
MAX6876ETX+T 功能描述:監控電路 EEPROM-Prog Quad Power-Sup Sequencer RoHS:否 制造商:STMicroelectronics 監測電壓數: 監測電壓: 欠電壓閾值: 過電壓閾值: 輸出類型:Active Low, Open Drain 人工復位:Resettable 監視器:No Watchdog 電池備用開關:No Backup 上電復位延遲（典型值）:10 s 電源電壓-最大:5.5 V 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:UDFN-6 封裝:Reel
MAX6876ETX-T 功能描述:監控電路 RoHS:否 制造商:STMicroelectronics 監測電壓數: 監測電壓: 欠電壓閾值: 過電壓閾值: 輸出類型:Active Low, Open Drain 人工復位:Resettable 監視器:No Watchdog 電池備用開關:No Backup 上電復位延遲（典型值）:10 s 電源電壓-最大:5.5 V 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:UDFN-6 封裝:Reel
MAX6876EVCMOD2 功能描述:監控電路 Programmers, Development Systems RoHS:否 制造商:STMicroelectronics 監測電壓數: 監測電壓: 欠電壓閾值: 過電壓閾值: 輸出類型:Active Low, Open Drain 人工復位:Resettable 監視器:No Watchdog 電池備用開關:No Backup 上電復位延遲（典型值）:10 s 電源電壓-最大:5.5 V 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:UDFN-6 封裝:Reel
MAX6876EVKIT 功能描述:監控電路 Programmers, Development Systems RoHS:否 制造商:STMicroelectronics 監測電壓數: 監測電壓: 欠電壓閾值: 過電壓閾值: 輸出類型:Active Low, Open Drain 人工復位:Resettable 監視器:No Watchdog 電池備用開關:No Backup 上電復位延遲（典型值）:10 s 電源電壓-最大:5.5 V 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:UDFN-6 封裝:Reel
