85
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER with CLOSED CAPTION DECODER
and ON-SCREEN DISPLAY CONTROLLER
M37280MFH–XXXSP, M37280MKH–XXXSP
M37280EKSP
MITSUBISHI MICROCOMPUTERS
Rev. 1.0
(2) OSD RAM (addresses 070016 to 07A716, 080016 to 0FFF16)
The OSD RAM for SPRITE consisting of 3 planes, is assigned to
addresses 070016 to 07A716. Each plane corresponds to each color
pallet selection bit and the color pallet of each dot is determined from
among 8 kinds.
The OSD RAM for character is allocated at addresses 080016 to
0FFF16, and is divided into a display character code specification
part, color code 1 specification part, and color code 2 specification
part for each block. Tables 8.11.5 and 8.11.6 show the contents of
the OSD RAM.
For example, to display 1 character position (the left edge) in block 1,
write the character code in address 080016, write color code 1 at
082016, and write color code 2 at 084016. The structure of the OSD
RAM is shown in Figure 8.11.23.
Note : For the layer 2 ’s OSD mode block with dot size of 1.5TC 1/2H and
1.5TC 1H, the 3nth (n = 1 to 10) character is skipped as compared
with ordinary block (blocks with dot size of 1TC 1/2H, or blocks on the
layer 1). Accordingly, maximum 22 characters are only displayed in 1
block. Blocks with dot size of 1TC 1/2H and 1TC 1H, or blocks on
the layer 1
However, note the following:
In OSD mode
The character is not displayed, and only the left 1/3 part of the 22nd
character back ground is displayed in the 22nd’s character area.
When not displaying this background, set transparent for background.
In CDOSD mode
The character is not displayed, and color pallet color specified by bit
3 to 6 of color code 1 can be output in the 22nd’s character area (left
1/3 part).
The RAM data for the 3nth character does not effect the display.
Any character data can be stored here (refer to Figure 8.11.22).
