External Components Description
(Figure 1)
Compo-
nents
1. R
i
Functional Description
Inverting input resistance which sets the closed-loop gain in conjuction with R
f
. This resistor also
forms a high pass filter with C
i
at f
c
= 1 / (2
π
R
i
C
i
).
Input coupling capacitor which blocks the DC voltage at the amplifier’s input terminals. Also creates a
highpass filter with R
i
at f
c
= 1 / (2
π
R
i
C
i
). Refer to the section,
Proper Selection of External
Components,
for and explanation of how to determine the value of C
i
.
Feedback resistance which sets closed-loop gain in conjuction with R
i
.
Supply bypass capacitor which provides power supply filtering. Refer to the
Application Information
section for proper placement and selection of the supply bypass capacitor.
Bypass pin capacitor which provides half-supply filtering. Refer to the section,
Proper Selection of
External Components,
for information concerning proper placement and selection of C
B
.
Output coupling capacitor which blocks the DC voltage at the amplifier’s output. Forms a high pass
filter with R
L
at f
O
= 1/(2
π
R
L
C
O
)
2. C
i
3. R
f
4. C
S
5. C
B
6. C
O
Typical Performance Characteristics
THD+N vs Frequency
DS100005-3
THD+N vs Frequency
DS100005-4
THD+N vs Frequency
DS100005-5
THD+N vs Frequency
DS100005-6
THD+N vs Frequency
DS100005-7
THD+N vs Frequency
DS100005-8
www.national.com
4
