33
July 8, 2005
TABLE OF MICROPROCESSOR DIRECT READ/WRITE ADDRESSES
ADD(2:0)
PINS
REGISTER DESCRIPTION
0
WR
Indirect Write Holding Register, Bits 15:0.
1
WR
Indirect Write Holding Register, Bits 31:16.
2
WR
Indirect Write Address Register for Internal Target Register (Generates a write strobe to transfer contents of the
Write Holding Register into the Target Register specified by the Indirect Address, see also Tables of Indirect
Address Registers).
3
WR
Indirect Read Address Register (Used to select the Read source of data - uses the same register as Direct
Address 2 but generates a read strobe (for RAMs and AGC) as needed instead of a write strobe).
0
RD
Indirect Read, Bits 15:0.
1
RD
Indirect Read, Bits 31:16.
2
RD
Read Register (FIFO) - Reads FIFO data from output section (This location reads output data in the order
loaded in Global Control Indirect Address Registers F820-F83F. The FIFO is automatically incremented to the
next data location at the end of each read).
3
RD
Status Register
P(15:0)
BIT DESCRIPTION
15:13
Unused.
12
BIST signature comparison result: 1= success (signatures match)
11:6
Read non-bus input pins (ENIx, RESET, SYNCI).
11 RESET (Note: This bit is inverted with respect to the RESET input pin).
10 ENIA.
9
ENIB.
8
ENIC.
7 ENID.
6
SYNCI.
5:2
Mask revision number. ISL5216 devices return 3 or higher (0, 1 and 2 were used for
HSP50216).
1
Level detector integration done. Active high.
0
New FIFO output data available (used for polling mode vs interrupt mode) Active low.
ISL5216
