IRLR/U3103PbF
HEXFET
Power MOSFET
S
D
G
V
DSS
= 30V
R
DS(on)
= 0.019
I
D
= 55A
Description
Fifth Generation HEXFETs from International Rectifier
utilize advanced processing techniques to achieve the
lowest possible on-resistance per silicon area. This
benefit, combined with the fast switching speed and
ruggedized device design that HEXFET Power
MOSFETs are well known for, provides the designer
with an extremely efficient device for use in a wide
variety of applications.
Parameter
Max.
55
39
220
107
0.71
± 16
240
34
11
5.0
Units
I
D
@ T
C
= 25°C
I
D
@ T
C
= 100°C
I
DM
P
D
@T
C
= 25°C
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
A
W
W/°C
V
mJ
A
mJ
V/ns
V
GS
E
AS
I
AR
E
AR
dv/dt
T
J
T
STG
-55 to + 175
300 (1.6mm from case )
°C
Absolute Maximum Ratings
Parameter
Typ.
–––
–––
–––
Max.
1.4
50
110
Units
R
θ
JC
R
θ
JA
R
θ
JA
www.irf.com
Junction-to-Case
Junction-to-Ambient (PCB mount) **
Junction-to-Ambient
°C/W
Thermal Resistance
D-PAK
TO-252AA
I-PAK
TO-251AA
Logic-Level Gate Drive
Ultra Low On-Resistance
Surface Mount (IRLR3103)
Straight Lead (IRLU3103)
Advanced Process Technology
Fast Switching
Fully Avalanche Rated
Lead-Free
The D-PAK is designed for surface mounting using
vapor phase, infrared, or wave soldering techniques.
The straight lead version (IRFU series) is for through-
hole mounting applications. Power dissipation levels
up to 1.5 watts are possible in typical surface mount
applications.
PD - 95085A
1
