This bit inhibits the transfer of RTC bytes to the user
buffer:
1 = Inhibits transfer and clears UIE
0 = Allows transfer
Register C
Register C is the read-only event status register.
Bits 0, 1, 2, 3 - Unused Bits
These bits are always set to 0.
UF - Update Event Flag
This bit is set toa1atthe end of the update cycle.
Reading register C clears this bit.
AF - Alarm Event Flag
This bit is set to a 1 when an alarm event occurs. Read-
ing register C clears this bit.
PF - Periodic Event Flag
This bit is set to a 1 every tPI time, where tPI is the time
period selected by the settings of RS0–RS3 in register A.
Reading register C clears this bit.
INTF - Interrupt Request Flag
This flag is set to a 1 when any of the following is true:
AIE = 1 and AF = 1
PIE = 1 and PF = 1
UIE = 1 and UF = 1
Reading register C clears this bit.
Register D
Register D provides for the read-only data integrity
status bit, and the day-of-the-month alarm.
Bits6-Unused Bit
This bit is always set to 0.
VRT - Valid RAM and Time
1 = Valid backup energy source
0 = Backup energy source is depleted
When the backup energy source is depleted (VRT = 0),
data integrity of the RTC and storage registers is not
guaranteed.
DA0–DA5
These bits store the value for the day-of-the-month
alarm. If DA0–DA5 are set to zero, then the day-of-the-
month alarm is disabled . These bits are not affected by
a reset.
10
7654
3
210
----
0
-
0
7654
3
210
---
UF
-
---
7654
3
210
--
AF
-
---
7654
3
210
-PF-
-
7654
3
210
INTF
-
July 1997
bq3285ED/LD
Register C Bits
7654
3
210
INTF
PF
AF
UF
0
-
0
7654
3
210
-0-
-
7654
3
210
-
DA5
DA4
DA3
DA2
DA1
DA0-
Register D Bits
7654
3
210
VRT
0
DA5
DA4
DA3
DA2
DA1
DA0
7654
3
210
VRT
-
