ADSP-2195
September 2001
Table 29
lists the mini-BGA pinout by ball number.
V
DDINT
D6
V
DDINT
F4
V
DDINT
G9
V
DDINT
J7
V
DDEXT
E5
V
DDEXT
E6
V
DDEXT
F5
V
DDEXT
F6
V
DDEXT
G7
V
DDEXT
G8
V
DDEXT
H7
V
DDEXT
H8
GND
A1
GND
A12
GND
E7
GND
F7
GND
F8
GND
F9
GND
G4
GND
G5
GND
G6
GND
H5
GND
L6
GND
M1
GND
M12
WR
C8
XTAL
B6
Table 28. 144-Lead Mini-BGA Pins (Alphabetically By
Signal)
(Continued)
SIGNAL
BALL #
Table 29. 144-Lead Mini-BGA Pins (Numerically By
Ball Number)
SIGNAL
BALL #
GND
A1
D13
A2
D9
A3
D5
A4
CLKIN
A5
D3
A6
D1
A7
ACK
A8
MS1
A9
BMS
A10
A21
A11
GND
A12
D14
B1
D15
B2
HAD1
B3
D11
B4
D7
B5
XTAL
B6
D4
B7
RD
B8
BR
B9
BGH
B10
A20
B11
A19
B12
HAD0
C1
HAD2
C2
D12
C3
D10
C4
D6
C5
