參數資料
| 型號： | 9LPRS480YKLFT |
| 廠商： | INTEGRATED DEVICE TECHNOLOGY INC |
| 元件分類： | 時鐘產生/分配 |
| 英文描述： | PROC SPECIFIC CLOCK GENERATOR, PQCC64 |
| 封裝： | ROHS COMPLIANT, PLASTIC, MLF-64 |
| 文件頁數： | 21/25頁 |
| 文件大小： | 249K |
| 代理商： | 9LPRS480YKLFT |
5
Integrated
Circuit
Systems, Inc.
ICS9LPRS480
1391D—02/02/09
TSSOP Pin Description
PIN #
PIN NAME
PIN TYPE
DESCRIPTION
1
REF1/SEL_SATA
I/O
14.318 MHz 3.3V reference clock./ 3.3V tolerant latched input to select function of SRC6/SATA output
0 = 100MHz differential spreading SRC clock, 1 = 100MHz non-spreading differential SATA clock
2
REF0/SEL_HTT66
I/O
14.318 MHz 3.3V reference clock./ 3.3V tolerant latched input to select Hyper Transport Clock
Frequency.
0 = 100MHz differential HTT clock, 1 = 66MHz 3.3V single ended HTT clock
3
GNDREF
GND
Ground pin for the REF outputs.
4
X1
IN
Crystal input, nominally 14.318MHz
5
X2
OUT
Crystal output, nominally 14.318MHz
6
VDD48
PWR
Power pin for the 48MHz outputs and core. 3.3V
7
48MHz_0
OUT
48MHz clock output.
8
GND48
GND
Ground pin for the 48MHz outputs
9
SMBCLK
IN
Clock pin of SMBus circuitry, 5V tolerant.
10
SMBDAT
I/O
Data pin for SMBus circuitry, 5V tolerant.
11
VDD27
PWR
3.3V Power supply for SRC/27MHz output and 27MHz SS PLL
12
SRC7C_LPRS/27MHz_NS
OUT
True clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33 ohm
series resistor needed)/27MHz 3.3V Single-ended non-spread output for discrete graphics
13
SRC7T_LPRS/27MHz_SS
OUT
Complement clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33
ohm series resistor needed)/27MHz 3.3V Single-ended spreading output for discrete graphics
14
GND27
GND
Ground for the SRC/27MHz outputs
15
SRC4C_LPRS
OUT
Complement clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33
ohm series resistor needed)
16
SRC4T_LPRS
OUT
True clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33 ohm
series resistor needed)
17
GNDSRC
GND
Ground pin for the SRC outputs
18
VDDSRC_IO
PWR
Power supply for differential SRC outputs, nominal 1.05V to 3.3V
19
SRC3C_LPRS
OUT
Complement clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33
ohm series resistor needed)
20
SRC3T_LPRS
OUT
True clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33 ohm
series resistor needed)
21
SRC2C_LPRS
OUT
Complement clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33
ohm series resistor needed)
22
SRC2T_LPRS
OUT
True clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33 ohm
series resistor needed)
23
VDDSRC
PWR
Supply for SRC core, 3.3V nominal
24
VDDSRC_IO
PWR
Power supply for differential SRC outputs, nominal 1.05V to 3.3V
25
GNDSRC
GND
Ground pin for the SRC outputs
26
SRC1C_LPRS
OUT
Complement clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33
ohm series resistor needed)
27
SRC1T_LPRS
OUT
True clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33 ohm
series resistor needed)
28
SRC0C_LPRS
OUT
Complement clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33
ohm series resistor needed)
29
SRC0T_LPRS
OUT
True clock of low power differential SRC clock pair. (no 50ohm shunt resistor to GND and no 33 ohm
series resistor needed)
30
*CLKREQ0#
IN
Clock Request pin for SRC0 outputs. If output is selected for control, then that output is controlled as
follows:
0 = enabled, 1 = Low-Low
31
GNDATIG
GND
Ground pin for the ATIG outputs
32
VDDATIG_IO
PWR
Power supply for differential ATIG outputs, nominal 1.05V to 3.3V
