www.ti.com
SLES164 – FEBBRUARY 2006
Fine Clamp Control
Subaddress
2Ah
Default (00h)
7
6
5
4
3
2
1
0
Reserved
Fine swsel[1:0]
Fine B
Fine G
Fine R
Fine swsel: Fine clamp time constant adjustment
00 = Highest (default), Recommended setting
01 =
10 =
11 = Lowest
Fine B:
0 = Blue channel fine clamp is off (default)
1 = Blue channel fine clamp is on, Recommended setting
Fine G:
0 = Green channel fine clamp is off (default)
1 = Green channel fine clamp is on, Recommended setting
Fine R:
0 = Red channel fine clamp is off (default)
1 = Red channel fine clamp is on, Recommended setting
NOTE:
Fine clamp must be turned on for proper clamp operation. See register 10h for mid
and bottom level clamping control.
Power Control
Subaddress
2Bh
(Default 00h)
7
6
5
4
3
2
1
0
SOG
SLICER
REF
CURRENT
PW ADC B
PW ADC G
PW ADC R
SOG:
0 = Normal operation (default)
1 = SOG power-down
Slicer:
0 = Normal operation (default)
1 = Slicer power-down
Reference:
0 = Normal operation (default)
1 = Reference block power-down
Current control:
0 = Normal operation (default)
1 = Current control block power-down
PW ADC B: Power-down ADC blue channel
0 = PW ADC R: Power-down ADC blue channel
1 = ADC channel 1 power-down
PW ADC G: Power-down ADC green channel
0 = PW ADC R: Power-down ADC green channel
1 = ADC channel 2 power-down
PW ADC R: Power-down ADC red channel
0 = PW ADC R: Power-down ADC red channel
1 = ADC channel 3 power-down
ADC Setup
Subaddress
2Ch
(Default 00h)
7
6
5
4
3
2
1
0
1
0
50h = Recommended setting
27
