www.ti.com
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED OPERATING CONDITIONS
TVP7000
SLES143 – SEPTEMBER 2005
TERMINAL FUNCTIONS (continued)
TERMINAL
I/O
DESCRIPTION
NAME
NO.
VSYNC_A
78
I
Vertical sync input A
VSYNC_B
79
I
Vertical sync input B. Unused inputs can be connected to ground.
HSYNC_A
81
I
Horizontal Sync input A
HSYNC_B
82
I
Horizontal Sync input B. Unused inputs can be connected to ground.
SOGIN1
1
I
Sync-on-green input 1
SOGIN2
99
I
Sync-on-green input 2
SOGIN3
97
i
Sync-on-green input 3. Unused inputs should be connected to ground using a 10 nF capacitor.
VSOUT
23
O
Vertical sync output
HSOUT
24
O
Horizontal sync output
SOGOUT
25
O
Sync-on-green slicer output
over operating free-air temperature range (unless otherwise noted)(1)
UNIT
IOVDD to IOGND
–0.5 V to 4.5 V
DVDD to GND
–0.5 V to 2.3 V
Supply voltage range
PLL_A18VDD to PLL_A18GND and A18VDD to A18GND
–0.5 V to 2.3 V
A33VDD to A33GND
– 0.5 V to 4.5 V
Digital input voltage range
VI to GND
–0.5 V to 4.5 V
Analog input voltage range
AI to A33GND
–0.2 V to 2.3 V
Digital output voltage range
VO to GND
–0.5 V to 4.5 V
TA
Operating free-air temperature
0
°C to 70°C
Tstg
Storage temperature
–65
°C to 150°C
(1)
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute–maximum–rated conditions for extended periods may affect device reliability.
over operating free-air temperature range, T
A = 0°C to 70°C (unless otherwise noted)
MIN
NOM
MAX
UNIT
IOVDD
Digital I/O supply voltage
3.0
3.3
3.6
V
DVDD
Digital supply voltage
1.70
1.8
1.9
V
PLL_A18VDD
Analog PLL supply voltage
1.70
1.8
1.9
V
A18VDD
Analog supply voltage
1.70
1.8
1.9
V
A33VDD
Analog supply voltage
3.0
3.3
3.6
V
VI(P–P)
Analog input voltage (ac–coupling necessary)
0.5
2.0
V
VIH
Digital input voltage high
0.7 IOVDD
V
VIL
Digital input voltage low
0.3 IOVDD
V
IOH
High–level output current
2
mA
IOL
Low–level output current
–2
mA
IOH_DATACLK
DATACLK high–level output current
4
mA
IOL_DATACLK
DATACLK low–level output current
–4
mA
TA
Operating free–air temperature
0
70
°C
5
