Functional Description
23
SLES141B—August 2007
TVP5146M2PFP
Table 24. I2C Host Interface Terminal Description
SIGNAL
TYPE
DESCRIPTION
I2CA
I
Slave address selection
SCL
I
Input clock line
SDA
I/O
Input/output data line
2.6.1 Reset and I2C Bus Address Selection
The TVP5146M2 decoder can respond to two possible chip addresses. The address selection is made at reset
by an externally supplied level on the I2CA terminal. The TVP5146M2 decoder samples the level of terminal
37 at power up or at the trailing edge of RESETB and configures the I2C bus address bit A0. The I2CA terminal
has an internal pulldown resistor to pull the terminal low to set a zero.
Table 25. I2C Address Selection
A6
A5
A4
A3
A2
A1
A0 (I2CA)
R/W
HEX
1
0
1
0
0 (default)
1/0
B9/B8
1
0
1
0
1
1/0
BB/BA
If terminal 37 is strapped to DVDD via a 2.2-k resistor, I2C device address A0 is set to 1.
2.6.2 I2C Operation
S
1011 1000
ACK
Subaddress
ACK
Send data
ACK
P
Data transfers occur using the following illustrated formats.
Read from I2C control registers
S
1011 1000
ACK
Subaddress
ACK
S
1011 1001
ACK
Receive data
NAK
P
S = I2C bus start condition
P = I2C bus stop condition
ACK = Acknowledge generated by the slave
NAK = Acknowledge generated by the master, for multiple-byte read master with ACK for each byte except
last byte
Subaddrress = Subaddress byte
Data = Data byte, if more than one byte of data is transmitted (read and write), the subaddress pointer is
automatically incremented.
I2C bus address = Example showing that I2CA is in default mode. Write (B8h), read (B9h)
2.6.3 VBUS Access
The TVP5146M2 decoder has additional internal registers accessible through an indirect access to an internal
24-bit address wide VBUS. Figure 219 shows the VBUS registers access.
