參數資料
| 型號： | SN74LVC1G29YEPR |
| 廠商： | TEXAS INSTRUMENTS INC |
| 元件分類： | 編、解碼器及復用、解復用 |
| 英文描述： | LVC/LCX/Z SERIES, OTHER DECODER/DRIVER, INVERTED OUTPUT, BGA8 |
| 封裝： | DSBGA-8 |
| 文件頁數： | 8/14頁 |
| 文件大?。?/td> | 328K |
| 代理商： | SN74LVC1G29YEPR |
www.ti.com
Absolute Maximum Ratings
(1)
2-OF-3 DECODER/DEMULTIPLEXER
SCES569A – JUNE 2004 – REVISED SEPTEMBER 2006
over operating free-air temperature range (unless otherwise noted)
MIN
MAX
UNIT
VCC
Supply voltage range
–0.5
6.5
V
VI
Input voltage range (2)
–0.5
6.5
V
VO
Voltage range applied to any output in the high-impedance or power-off state(2)
–0.5
6.5
V
VO
Voltage range applied to any output in the high or low state(2)(3)
–0.5
VCC + 0.5
V
IIK
Input clamp current
VI < 0
–50
mA
IOK
Output clamp current
VO < 0
–50
mA
IO
Continuous output current
±50
mA
Continuous current through VCC or GND
±100
mA
DCT package
220
θ
JA
Package thermal impedance(4)
DCU package
227
°C/W
YEP/YZP package
102
Tstg
Storage temperature range
–65
150
°C
(1)
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2)
The input and output negative-voltage ratings may be exceeded if the input and output current ratings are observed.
(3)
The value of VCC is provided in the recommended operating conditions table.
(4)
The package thermal impedance is calculated in accordance with JESD 51-7.
3
