80C32/80C52
17
Rev. I
–
September 18, 1998
Table 7. Maximum Icc (mA)
Operating
(1)
IDLE
(2)
FREQUENCY/VCC
2.7 V
3 V
3.3 V
5.5 V
2.7 V
3 V
3.3 V
5.5 V
1 MHz
0.8 mA
1 mA
1.1 mA
1.8 mA
400
μ
A
500
μ
A
600
μ
A
1 mA
6 MHz
4 mA
5 mA
6 mA
10 mA
1.5 mA
1.7 mA
2 mA
4 mA
12 MHz
8 mA
10 mA
12 mA
2.5 mA
3 mA
3.5 mA
16 MHz
10 mA
12 mA
14 mA
3 mA
3.8 mA
4.5 mA
Freq > 12 MHz (VCC= 5.5 V)
Icc (mA)= 1.25
×
Freq (MHz) + 5
Icc Idle (mA)= 0.36
×
Freq (MHz) + 2.7
Notes:
1.
ICC is measured with all output pins disconnected; XTAL1 driven with TCLCH, TCHCL= 5 ns, VIL= VSS + .5 V, VIH= VCC –.5 V; XTAL2
N.C. ; EA= RST= Port 0= VCC. ICC would be slighty higher if a crystal oscillator used.
Idle ICC is measured with all output pins disconnected ; XTAL1 driven with TCLCH, TCHCL= 5 ns, VIL= VSS + 5 V, VIH= VCC –.5 V ;
XTAL2 N.C; Port 0= VCC; EA= RST= VSS.
Power Down ICC is measured with all output pins disconnected; EA= PORT 0= VCC; XTAL2 N.C. ; RST= VSS.
Capacitance loading on Ports 0 and 2 may cause spurious noise pulses to be superimposed on the VOLS of ALE and Ports 1 and 3. The
noise is due to external bus capacitance discharging into the Port 0 and Port 2 pins when these pins make 1 to 0 transitions during bus
operations. In the worst cases (capacitive loading 100 pF), the noise pulse on the ALE line may exceed 0.45 V may exceed 0,45 V with maxi
VOL peak 0.6 V. A Schmitt Trigger use is not necessary.
2.
3.
4.
Figure 9. ICC Test Condition, Idle Mode. All other pins are disconnected
Figure 10. ICC Test Condition, Active Mode. All other pins are disconnected
