8.4. DC parameters –Military
Table 5. DC Parameters
TA= –55
°
C + 125
°
C; VSS= 0 V; VCC= 5 V
±
10 %; F= 0 to 36 MHz
Symbol
Parameter
Min
Max
Unit
Test Conditions
VIL
Input Low Voltage
– 0.5
0.2 VCC –
0.1
V
VIH
Input High Voltage (Except XTAL and RST)
0.2 VCC + 1.4
VCC + 0.5
V
VIH1
Input High Voltage (for XTAL and RST)
0.7 VCC
VCC + 0.5
V
VOL
Output Low Voltage (Port 1, 2 and 3)
0.45
V
IOL= 1.6 mA
(4)
VOL1
Output Low Voltage (Port 0, ALE, PSEN)
0.45
V
IOL= 3.2 mA
(4)
VOH
Output High Voltage (Port 1, 2 and 3)
2.4
V
IOH= – 60
μ
A
VCC= 5 V
±
10 %
0.75 VCC
V
IOH= – 25
μ
A
0.9 VCC
V
IOH= – 10
μ
A
VOH1
Output High Voltage
(Port 0 in External Bus Mode, ALE, PEN)
2.4
V
IOH= – 400
μ
A
VCC= 5 V
±
10 %
0.75 VCC
V
IOH= – 150
μ
A
0.9 VCC
V
IOH= – 40
μ
A
IIL
Logical 0 Input Current (Ports 1, 2 and 3)
– 75
μ
A
Vin= 0.45 V
ILI
Input leakage Current
+/– 10
μ
A
0.45 < Vin < VCC
ITL
Logical 1 to 0 Transition Current (Ports 1, 2 and 3)
– 750
μ
A
Vin= 2.0 V
IPD
Power Down Current
75
μ
A
VCC= 2.0 V to 5.5 V
(3)
RRST
RST Pulldown Resistor
50
200
K
CIO
Capacitance of I/O Buffer
10
pF
MHz, Ta= 25 C
ICC
Power Supply Current
Freq= 1 MHz
Icc op
Icc idle
Icc op
Icc idle
Freq= 6 MHz
Freq
≥
12 MHz Icc op= 1.25 Freq (MHz) + 5 mA
Icc idle= 0.36 Freq (MHz) + 2.7 mA
1.8
1
10
4
mA
mA
mA
mA
VCC= 5.5 V
Notes:
1.
ICC is measured with all output pins disconnected; XTAL1 driven with TCLCH, TCHCL= 5 ns, VIL= VSS + .5 V, VIH= VCC –.5 V; XTAL2
N.C. ; EA= RST= Port 0= VCC. ICC would be slighty higher if a crystal oscillator used.
Idle ICC is measured with all output pins disconnected ; XTAL1 driven with TCLCH, TCHCL= 5 ns, VIL= VSS + 5 V, VIH= VCC –.5 V ;
XTAL2 N.C; Port 0= VCC; EA= RST= VSS.
Power Down ICC is measured with all output pins disconnected; EA= PORT 0= VCC; XTAL2 N.C. ; RST= VSS.
Capacitance loading on Ports 0 and 2 may cause spurious noise pulses to be superimposed on the VOLS of ALE and Ports 1 and 3. The
noise is due to external bus capacitance discharging into the Port 0 and Port 2 pins when these pins make 1 to 0 transitions during bus
operations. In the worst cases (capacitive loading 100 pF), the noise pulse on the ALE line may exceed 0.45 V may exceed 0,45 V with maxi
VOL peak 0.6 V. A Schmitt Trigger use is not necessary.
