NST3946DXV6T1, NST3946DXV6T5
http://onsemi.com
2
Characteristic
(Both Junctions Heated)
Symbol
Max
Unit
Thermal Resistance Junction-to-Ambient
R
JA
250
(Note 1)
°
C/W
Junction and Storage Temperature Range
T
J
, T
stg
- 55 to
+150
°
C
ELECTRICAL CHARACTERISTICS
(T
A
= 25
°
C unless otherwise noted)
Characteristic
Symbol
Min
Max
Unit
OFF CHARACTERISTICS
Collector- Emitter Breakdown Voltage (Note 2)
(I
C
= 1.0 mAdc, I
B
= 0)
(I
C
= -1.0 mAdc, I
B
= 0)
(NPN)
(PNP)
V
(BR)CEO
40
-40
-
-
Vdc
Collector- Base Breakdown Voltage
(I
C
= 10 Adc, I
E
= 0)
(I
C
= -10 Adc, I
E
= 0)
(NPN)
(PNP)
V
(BR)CBO
60
-40
-
-
Vdc
Emitter- Base Breakdown Voltage
(I
E
= 10 Adc, I
C
= 0)
(I
E
= -10 Adc, I
C
= 0)
(NPN)
(PNP)
V
(BR)EBO
6.0
-5.0
-
-
Vdc
Base Cutoff Current
(V
CE
= 30 Vdc, V
EB
= 3.0 Vdc)
(V
CE
= -30 Vdc, V
EB
= -3.0 Vdc)
(NPN)
(PNP)
I
BL
-
-
50
-50
nAdc
Collector Cutoff Current
(V
CE
= 30 Vdc, V
EB
= 3.0 Vdc)
(V
CE
= -30 Vdc, V
EB
= -3.0 Vdc)
(NPN)
(PNP)
I
CEX
-
-
50
-50
nAdc
ON CHARACTERISTICS
(Note 2)
DC Current Gain
(I
C
= 0.1 mAdc, V
CE
= 1.0 Vdc)
(I
C
= 1.0 mAdc, V
CE
= 1.0 Vdc)
(I
C
= 10 mAdc, V
CE
= 1.0 Vdc)
(I
C
= 50 mAdc, V
CE
= 1.0 Vdc)
(I
C
= 100 mAdc, V
CE
= 1.0 Vdc)
(NPN)
(I
C
= -0.1 mAdc, V
CE
= -1.0 Vdc)
(I
C
= -1.0 mAdc, V
CE
= -1.0 Vdc)
(I
C
= -10 mAdc, V
CE
= -1.0 Vdc)
(I
C
= -50 mAdc, V
CE
= -1.0 Vdc)
(I
C
= -100 mAdc, V
CE
= -1.0 Vdc)
(PNP)
h
FE
40
70
100
60
30
60
80
100
60
30
-
-
300
-
-
-
-
300
-
-
-
Collector- Emitter Saturation Voltage
(I
C
= 10 mAdc, I
B
= 1.0 mAdc)
(I
C
= 50 mAdc, I
B
= 5.0 mAdc)
(NPN)
(I
C
= -10 mAdc, I
B
= -1.0 mAdc)
(I
C
= -50 mAdc, I
B
= -5.0 mAdc)
(PNP)
V
CE(sat)
-
-
-
-
0.2
0.3
-0.25
-0.4
Vdc
Base- Emitter Saturation Voltage
(I
C
= 10 mAdc, I
B
= 1.0 mAdc)
(I
C
= 50 mAdc, I
B
= 5.0 mAdc)
(NPN)
(I
C
= -10 mAdc, I
B
= -1.0 mAdc)
(I
C
= -50 mAdc, I
B
= -5.0 mAdc)
(PNP)
V
BE(sat)
0.65
-
-0.65
-
0.85
0.95
-0.85
-0.95
Vdc
2. Pulse Test: Pulse Width
≤
300
μ
s; Duty Cycle
≤
2.0%.
