SWITCHING CHARACTERISTICS (VDD = +3.3 V, TA = 25°C, unless otherwise specified)
Symbol
Characteristics
Conditions
Min
Typ
Max
Unit
TSK1
Bittobit skew within same
differential channel
RS = 50 W, RL = 200 W, CL = 4 pF
7
ps
TSK2
Channeltochannel skew
RS = 50 W, RL = 200 W, CL = 4 pF
55
ps
SELECTION PINS SWITCHING CHARACTERISTICS (VDD = +3.3 V, TA = 25°C, unless otherwise specified)
Symbol
Characteristics
Conditions
Min
Typ
Max
Unit
TSELON
SEL to Switch turn ON time
VDX_A or VDX_B = +1.0 V, RL = 50 W,
VHPD_ X or VAUX_X = +1.0 V, RL = 50 W,
LE = VDD, CL = 100 pf
8
20
ns
TSELOFF
SEL to Switch turn OFF time
VDX_A or VDX_B = +1.0 V, RL = 50 W,
VHPD_ X or VAUX_X = +1.0 V, RL = 50 W,
LE = VDD, CL = 100pf
5
10
ns
TSET
LE setup time SEL to LE
VDX_A or VDX_B = +1.0 V, RL = 50 W,
VHPD_ X or VAUX_X = +1.0 V, RL = 50 W,
LE = VDD, CL = 100 pf
1
ns
THOLD
LE hold time LE to SEL
VDX_A or VDX_B = +1.0 V, RL = 50 W,
VHPD_ X or VAUX_X = +1.0 V, RL = 50 W,
LE = VDD, CL = 100 pf
1
ns
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
