Semiconductor Components Industries, LLC, 2006
January, 2006
Rev. 1
1
Publication Order Number:
NB7L111M/D
NB7L111M
2.5V / 3.3V, 6.125Gb/s 1:10
Differential Clock/Data
Driver with CML Output
Description
The NB7L111M is a low skew 1–to–10 differential clock/data
driver, designed with clock/data distribution in mind. It accepts two
clock/data sources into multiplexer input and reproduces ten identical
CML differential outputs. This device is ideal for clock/data
distribution across the backplane or a board, and redundant clock
switchover applications.
The input signals can be either differential or single–ended (if the
external reference voltage is provided). Differential inputs incorporate
internal 50 termination resistors and accept Negative ECL (NECL),
Positive ECL (PECL), LVCMOS, LVTTL, CML, or LVDS (using
appropriate power supplies). The differential 16 mA CML output
provides matching internal 50
termination, and 400 mV output
swing when externally terminated 50 to V
CC.
The NB7L111M operates from a 2.5 V
3.3 V
5% supply and is guaranteed over the full industrial
temperature range of
40
°
C to +85
°
C. This device is packaged in a
low profile 8x8 mm, QFN
52 package with 0.5 mm pitch (see
package dimension on the back of the datasheet).
Application notes, models, and support documentation are available
at www.onsemi.com.
5% supply or a
Features
Maximum Input Clock Frequency > 5.5 GHz Typical
Maximum Input Data Rate > 6.125 Gb/s Typical
< 0.5 ps Maximum Clock RMS Jitter
< 15 ps Maximum Data Dependent Jitter at 3.125 Gb/s
50 ps Typical Rise and Fall Times
240 ps Typical Propagation Delay
2 ps Typical Duty Cycle Skew
10 ps Typical Within Device Skew
15 ps Typical Device
to
Device Skew
Operating Range: V
CC
= 2.5 V
400 mV Differential CML Output Swing
50 Internal Input and Output Termination Resistors
Pb
Free Packages are Available*
5 and 3.3 V
5
*For additional information on our Pb
Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
A
WL
YY
WW
G
= Assembly Site
= Wafer Lot
= Year
= Work Week
= Pb
Free Package
*For additional marking information, refer to
Application Note AND8002/D.
QFN
52
MN SUFFIX
CASE 485M
MARKING DIAGRAM*
52
http://onsemi.com
See detailed ordering and shipping information in the package
dimensions section on page 12 of this data sheet.
ORDERING INFORMATION
1
52
NB7L
111M
AWLYYWWG
1
