SLAS697A
– MARCH 2010 – REVISED FEBRUARY 2011
TERMINAL FUNCTIONS (64-PM PACKAGE)
TERMINAL
I/O
DESCRIPTION
NAME
PM
Analog supply voltage, positive terminal. Supplies only the analog portion of
AVCC
64
ADC12 and DAC12.
Analog supply voltage, negative terminal. Supplies only the analog portion of
AVSS
62
ADC12 and DAC12.
DVCC1
1
Digital supply voltage, positive terminal. Supplies all digital parts.
DVSS1
63
Digital supply voltage, negative terminal. Supplies all digital parts.
General-purpose digital I/O pin/Timer_A, clock signal TACLK
P1.0/TACLK/CAOUT
12
I/O
input/Comparator_A output
General-purpose digital I/O pin/Timer_A, capture: CCI0A input, compare:
P1.1/TA0
13
I/O
Out0 output/BSL transmit
General-purpose digital I/O pin/Timer_A, capture: CCI1A input, compare:
P1.2/TA1
14
I/O
Out1 output
General-purpose digital I/O pin/Timer_A, capture: CCI2A input, compare:
P1.3/TA2
15
I/O
Out2 output
P1.4/SMCLK
16
I/O
General-purpose digital I/O pin/SMCLK signal output
P1.5/TA0
17
I/O
General-purpose digital I/O pin/Timer_A, compare: Out0 output
P1.6/TA1
18
I/O
General-purpose digital I/O pin/Timer_A, compare: Out1 output
P1.7/TA2
19
I/O
General-purpose digital I/O pin/Timer_A, compare: Out2 output
P2.0/ACLK/CA2
20
I/O
General-purpose digital I/O pin/ACLK output/Comparator_A input
P2.1/TAINCLK/CA3
21
I/O
General-purpose digital I/O pin/Timer_A, clock signal at INCLK
General-purpose digital I/O pin/Timer_A, capture: CCI0B
P2.2/CAOUT/TA0/CA4
22
I/O
input/Comparator_A output/BSL receive/Comparator_A input
General-purpose digital I/O pin/Timer_A, compare: Out1
P2.3/CA0/TA1
23
I/O
output/Comparator_A input
General-purpose digital I/O pin/Timer_A, compare: Out2
P2.4/CA1/TA2
24
I/O
output/Comparator_A input
General-purpose digital I/O pin/input for external resistor defining the DCO
P2.5/Rosc/CA5
25
I/O
nominal frequency/Comparator_A input
General-purpose digital I/O pin/conversion clock
– 12-bit ADC/DMA channel
P2.6/ADC12CLK/DMAE0/CA6
26
I/O
0 external trigger/Comparator_A input
General-purpose digital I/O pin/Timer_A, compare: Out0
P2.7/TA0/CA7
27
I/O
output/Comparator_A input
General-purpose digital I/O pin/USCI B0 slave transmit enable/USCI A0
P3.0/UCB0STE/UCA0CLK
28
I/O
clock input/output
General-purpose digital I/O pin/USCI B0 slave in/master out in SPI mode,
P3.1/UCB0SIMO/UCB0SDA
29
I/O
SDA I2C data in I2C mode
General-purpose digital I/O pin/USCI B0 slave out/master in in SPI mode,
P3.2/UCB0SOMI/UCB0SCL
30
I/O
SCL I2C clock in I2C mode
General-purpose digital I/O/USCI B0 clock input/output, USCI A0 slave
P3.3/UCB0CLK/UCA0STE
31
I/O
transmit enable
General-purpose digital I/O pin/USCIA transmit data output in UART mode,
P3.4/UCA0TXD/UCA0SIMO
32
I/O
slave data in/master out in SPI mode
General-purpose digital I/O pin/USCI A0 receive data input in UART mode,
P3.5/UCA0RXD/UCA0SOMI
33
I/O
slave data out/master in in SPI mode
General-purpose digital I/O pin/USCI A1 transmit data output in UART
P3.6/UCA1TXD/UCA1SIMO
34
I/O
mode, slave data in/master out in SPI mode
General-purpose digital I/O pin/USCIA1 receive data input in UART mode,
P3.7/UCA1RXD/UCA1SOMI
35
I/O
slave data out/master in in SPI mode
General-purpose digital I/O pin/Timer_B, capture: CCI0A/B input, compare:
P4.0/TB0
36
I/O
Out0 output
General-purpose digital I/O pin/Timer_B, capture: CCI1A/B input, compare:
P4.1/TB1
37
I/O
Out1 output
General-purpose digital I/O pin/Timer_B, capture: CCI2A/B input, compare:
P4.2/TB2
38
I/O
Out2 output
6
2010–2011, Texas Instruments Incorporated
Product Folder Link(s): MSP430F2619S-HT
