Semiconductor
MSM9005-xx
15/30
FEDL9005-03
Reset Function
Reset is enabled when the RST pin is set at "L" level at such timing as at power-on, which
initializes all functions and turns off the LCD panel.
The initial state after reset is as follows.
Data of each RAM ........... All contents are held. (Contents are undefined when power is turned
on.)
Arbitrator blink ............... Writing in 5 dot units is set.
Character blink ................ Repeat of all display-on and character display is set.
Display on and
all display off ................... All display off mode is selected.
Segment output ............... All segment outputs go to VDD level.
Common output.............. All common outputs go to VDD level.
SO pin ............................... High impedance state
