Semiconductor
MSM9005-xx
20/30
FEDL9005-03
[How to transfer LPA command, ABBC 1/5 command and CHB command (character blink
setting)]
11*00000
D8 D7 D6 D5 D4 D3 D2 D1
LPA
command
(Repeats nine times.)
0***00
CB
D8 D7 D6 D5 D4 D3 D2 D1
CHB
command
0***00
CB
*
D8 D7 D6 D5 D4 D3 D2 D1
CHB
command
0***00
CB
*
D8 D7 D6 D5 D4 D3 D2 D1
CHB
command
0***00
CB
*
D8 D7 D6 D5 D4 D3 D2 D1
CHB
command
0***00
CB
*
D8 D7 D6 D5 D4 D3 D2 D1
CHB
command
*
Specify the address pointer value.
(Example: Set the address pointer value to 00H.)
CB value is written to CHB RAM address 00H and the
blinking of characters displayed in segments 1 to 5 is set.
After this command is executed, the address pointer value
becomes 01H.
CB value is written to CHB RAM address 01H, and the
blinking of characters displayed in segments 6 to 10 is set.
After this command is executed, the address pointer value
becomes 02H.
CB value is written to CHB RAM address 0BH and the
blinking of characters displayed in segments 56 to 60 is set.
After this command is executed, the address pointer value
becomes 0CH.
CB value is written to CHB RAM address 0CH, and the
blinking of characters displayed in segments 61 to 65 is set.
After this command is executed, the address pointer value
becomes 0DH.
CHB RAM address is only 00H to 0CH. The address
pointer value becomes 0DH. However, this CHB
command is ignored.
*: Don't care
