Semiconductor
ML670100
/ 27
16
ELECTRICAL CHARACTERISTICS
Absolute Maximum ratings
Item
Symbol
Condition
Rated Value
Unit
Power supply
VDD
-0.3 to 4.6
V
Input voltage
VIN
VDD=AVDD=VREF
-0.3 to VDD +0.3
Analog input voltage
VAI
GND=AGND=0V
-0.3 to AVDD +0.3
V
Output current
IO
12
mA
Power dissipation
PD
Ta=25V
850
mW
Storage temperature
TSTG
-
-55 to +150
°C
Recommended Operating Conditions
(Condition: GND=AGND=0V)
Item
Symbol
Condition
Min.
Typ.
Max.
Unit
Power supply
VDD
-
2.7
3.3
3.6
Analog power supply
AVDD
VDD=AVDD
2.7
3.3
3.6
V
Analog reference
voltage
VREF
-
AVDD-0.3
-
AVDD
Analog input voltage
VAI
-
AGND
-
VREF
Operating Frequency 1
fC1
VDD =3.0 to 3.6V, 1
4
-
25
Operating Frequency 2
fC2
VDD =2.7 to 3.6V, 2
4
-
20
MHz
Ambient temperature
Ta
-40
25
+85
°C
1
Basic clock frequency
from the oscillator
circuit or an external
clock signal
PLLEN Input
FSEL Input
Operating Frequency 1
fC1
4 - 6.25MHz
“H” level
“H” level (Connect to VDD)
4 - 25MHz
8 - 12.5MHz
(Connect to VDD)
“L” level (Connect to GND)
4 - 25MHz
(External clock only)
“L” level
(Connect to GND)
“H” level (Connect to VDD)
or
“L” level (Connect to GND)
4 - 25MHz
2
Basic clock frequency
from the oscillator
circuit or an external
clock signal
PLLEN Input
FSEL Input
Operating Frequency 2
fC2
4 - 5MHz
“H” level
“H” level (Connect to VDD)
4 - 20MHz
8 - 10MHz
(Connect to VDD)
“L” level (Connect to GND)
4 - 20MHz
(External clock only)
“L” level
(Connect to GND)
or
“L” level (Connect to GND)
4 - 20MHz
