Semiconductor Components Industries, LLC, 2000
March, 2000 – Rev. 6
1
Publication Order Number:
MC10H176/D
The MC10H176 contains six master slave type D flip–flops with a
common clock. This MECL 10H part is a functional/pinout
duplication of the standard MECL 10K family part, with 100%
improvement in clock frequency and propagation delay and no
increase in power–supply current.
Propagation Delay, 1.7 ns Typical
Power Dissipation, 460 mW Typical
Improved Noise Margin 150 mV (Over Operating Voltage and
Temperature Range)
Voltage Compensated
MECL 10K–Compatible
CLOCKED TRUTH TABLE
DIP
PIN ASSIGNMENT
VCC1
Q0
Q1
Q2
D0
D1
D2
VEE
VCC2
Q5
Q4
Q3
D5
D4
D3
CLOCK
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
* A clock H is a clock transition from
a low to a high state.
C
L
H *
H *
Q
X
L
H
Qn+1
Qn
L
H
Pin assignment is for Dual–in–Line Package.
For PLCC pin assignment, see the Pin Conversion Tables on page 18
of the ON Semiconductor MECL Data Book (DL122/D).
http://onsemi.com
Device
Package
Shipping
ORDERING INFORMATION
MC10H176L
CDIP–16
25 Units/Rail
MC10H176P
PDIP–16
25 Units/Rail
MC10H176FN
PLCC–20
46 Units/Rail
MARKING
DIAGRAMS
16
1
A
WL = Wafer Lot
YY
= Year
WW = Work Week
= Assembly Location
CDIP–16
L SUFFIX
CASE 620
MC10H176L
AWLYYWW
PDIP–16
P SUFFIX
CASE 648
PLCC–20
FN SUFFIX
CASE 775
10H176
AWLYYWW
1
1
16
MC10H176P
AWLYYWW
