30707 TI IM A8-8315 No.4164-1/8
LB1816
Overview
LB1816 is a 3-phase brushless motor driver IC with an on-chip speed control circuit. It is optimal for use in optical disc
(both 5.25 inches and 3.5 inches) spindle motor drive.
Functions and Features
Three-phase full-wave current linear drive
Output soft switching
Digital PLL speed control
Phase lock detection output
On-chip FG amplifier, integrating amplifiers
Reverse torque braking (with power-on reset function)
Crystal oscillator circuit
Clock frequency division switching (3 internal clock mode settings + external clock input)
Current limiter circuit
Low power supply voltage protection circuit (LVSD)
Internal regulator output (6.3V)
Thermal protection circuit (TSD)
Built-in spark killer diode
Built-in Hall amplifier AGC circuit
Ordering number : EN4164B
Monolithic Digital IC
Single-Chip IC for ODD Spindles
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
's products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
