22107 TI IM B8-3973 No.6506-1/5
LB1933M
Overview
The 1933M is a forward/reverse motor driver that supports low voltage drive and features low-saturation outputs in a
miniature package.
Features
Low saturation output: VOsat=0.3V typ (IO=300mA)
Specifications
Absolute Maximum Ratings at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
VCC max
-0.3 to +10.5
V
Maximum supply voltage
VS max
-0.3 to +10.5
V
Maximum Output applied voltage
VOUT
VS+VSF
V
Maximum input applied voltage
VIN
-0.3 to +10.0
V
Maximum output current
IGND
Per channel
1.0
A
Pd max1
Independent IC
550
mW
Allowable power dissipation
Pd max2
* Mounted on a specified board
800
mW
Operating temperature
Topr
-30 to +75
°C
Storage temperature
Tstg
-40 to +150
°C
Note *: Mounted on a specified board: 30mm
×30mm×1.5mm, glass epoxy
Ordering number : EN6505
Monolithic Digital IC
Low-saturation
Forward/Reverse Motor Drive
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
's products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
