| 型號： | KMD2ALB7BBBNR1 |
| 廠商： | THE CHERRY CORP |
| 元件分類： | 開關 |
| 英文描述： | ROCKER SWITCH, SPST, LATCHED, 21A, 14VDC, PANEL MOUNT |
| 文件頁數： | 1/2頁 |
| 文件大?。?/td> | 923K |
| 代理商： | KMD2ALB7BBBNR1 |
Nylon slide (TIP)
Copper alloy
contact holder
Copper alloy terminals
Steel spring
Nylon rocker
EPDM O ring
Nylon base
Nylon tip holder
Copper alloy
contact plate
Silver contacts
Nylon frame
Features
Enclosed switch complying to IP56
Available in single- or double-pole
Lighted and non-lighted versions
Maintained-action and
momentary options
Snap-in mounting
Mechanical life: 100,000 cycles
DC electrical life: 25,000 cycles
Electrical Ratings
Switch
Series
KM
Electrical Life at Rated Load
(Min. Operations)
6,000
Rating
20A125VAC; 10A 250VAC; 21A 14VDC
WATERPROOF ROCKER SWITCH
KM Series
Specifications
Electrical
Dielectric Strength:
Insulation Resistance:
Initial Contact Resistance:
Temperature Rating:
1500VAC for 1minute
10
8
ohms min at 500VDC
0.050 ohms max
-20°C to +85°C
Materials
Actuator:
Housing:
Bezel:
Spring:
Contacts:
Movable Arm:
Terminals:
Soft Material Molded Polycarbonate Lens
Nylon 66 94V-2 min.
Nylon 66 with 33% Glass Fiber
Steel Wire
Silver-plated Copper Alloy
Silver-plated Copper Alloy
Silver-plated Copper Alloy (except lamp terminal)
